John Deere 160G LC
Browse All John Deere or Hydraulic Excavator Models
Contents:
Dimensions
| Ground Clearance | 1.55 ft in (470 mm) |
| Height To Top Of Cab | 9.68 ft in (2950 mm) |
| Tail Swing Radius | 9.55 ft in (2910 mm) |
| Removal Counterweight Clearance | 3.38 ft in (1030 mm) |
Undercarriage
| Number Of Track Rollers Per Side | 7 |
| Number Of Carrier Rollers Per Side | 2 |
| Max Travel Speed | 3.3 mph (5.32 km/h) |
| Drawbar Pull | 35521 lb (158.01 kN) |
| Number Of Shoes Per Side | 43 |
Engine
| Engine Make | 2240 |
| Engine Model | PowerTech PWS 4.5 L |
| Net Power | 122 hp (91 kw) |
| Displacement | 274.7 cu in (4.5 L) |
Operational
| Operating Weight | 29526 lb (13392.8 kg) |
| Fuel Capacity | 75.3 gal (285.1 L) |
| Cooling System Fluid Capacity | 6.3 gal (23.5 L) |
| Hydraulic System Fluid Capacity | 33 gal (125 L) |
| Engine Oil Capacity | 4.5 gal (17 L) |
| Swing Drive Fluid Capacity | 1.7 gal (6.2 L) |
Swing Mechanism
| Swing Speed | 13.3 rpm |
| Swing Torque | 32353 lb ft (43864.8 Nm) |
