John Deere 200C LC Super Long Front
Browse All John Deere or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 39.24 ft in (11960 mm) |
| Shipping Height Of Unit | 9.68 ft in (2950 mm) |
| Max Loading Height | 36.91 ft in (11250 mm) |
| Max Reach Along Ground | 50.6 ft in (15420 mm) |
| Max Digging Depth | 37.93 ft in (11560 mm) |
| Boom/Stick Option (Hex) 1 | 24ft 3in stick |
Dimensions
| Ground Clearance | 1.5 ft in (457 mm) |
| Height To Top Of Cab | 9.68 ft in (2950 mm) |
| Width To Outside Of Tracks | 10.5 ft in (3200 mm) |
| Length Of Track On Ground | 12.01 ft in (3660 mm) |
| Tail Swing Radius | 8.99 ft in (2740 mm) |
| Removal Counterweight Clearance | 3.38 ft in (1030 mm) |
Undercarriage
| Track Gauge | 7.83 ft in (2390 mm) |
| Shoe Size | 31.89 in (810 mm) |
| Drawbar Pull | 42420 lb (188.7 kN) |
| Number Of Track Rollers Per Side | 8 |
| Max Travel Speed | 3.42 mph (5.5 km/h) |
| Number Of Carrier Rollers Per Side | 2 |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2240 |
| Engine Model | 6068H |
| Net Power | 141 hp (105.2 kw) |
| Power Measured @ | 2150 rpm |
| Displacement | 414 cu in (6.8 L) |
Operational
| Operating Weight | 48430 lb (21967.5 kg) |
| Fuel Capacity | 95.2 gal (360 L) |
| Hydraulic System Fluid Capacity | 34 gal (128.7 L) |
| Hydraulic System Relief Valve Pressure | 4980 psi (34335.9 kPa) |
| Hydraulic Pump Flow Capacity | 115.8 gal/min (438 L/min) |
Swing Mechanism
| Swing Speed | 13.3 rpm |
Buckets
| Reference Bucket Capacity | 0.5 yd3 (0.4 m3) |
| Minimum Bucket Capacity | 0.5 yd3 (0.4 m3) |
| Maximum Bucket Capacity | 0.8 yd3 (0.6 m3) |
