| Max Cutting Height | 34.5 ft in (10515.6 mm) |
| Max Reach Along Ground | 34.11 ft in (10396.73 mm) |
| Max Vertical Wall Digging Depth | 40.5 ft in (12344.4 mm) |
| Max Digging Depth | 21.3 ft in (6492.24 mm) |
| Bucket Digging Force - Sae | 56202.24 lb (250 kN) |
| Horizontal Digging Stroke - Ground Level | 11.9 ft in (3627.12 mm) |
| Max Digging Reach | 35.8 ft in (10911.84 mm) |
| Max Dumping Clearance | 22.8 ft in (6949.44 mm) |
| Arm Crowd Force-Iso | 55527.81 lb (247 kN) |
| Arm Crowd Force - Sae | 53054.91 lb (236 kN) |
| Boom/Stick Option (Hex) 1 | Boom length 28 ft 8 in 6.3 m , arm length 7 ft 10 in 2.4 m |
| Bucket Digging Force - Iso | 62721.69 lb (279 kN) |
| Min Dumping Clearance | 10.2 ft in (3108.96 mm) |
| Minimum Swing Radius | 187.01 in (4750 mm) |
