Tadano TM1052
Browse All Tadano or Hydraulic Truck Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 13.6 ft in (4.15 m) |
| Max Height @ Max Raise Angle - No Jib | 51.4 ft in (15.67 m) |
| Min Working Radius | 5 ft in (1.53 m) |
| Max Working Radius | 45 ft in (13.72 m) |
| Max Elevating Angle | 82 degrees |
| Max Lift Capacity | 20000 lb (9071.85 kg) |
| Number Of Sections | 5 |
| Swing Speed | 2.5 rpm |
Dimensions
| Transport Width | 3.67 ft in (1118 mm) |
| Transport Height | 10.7 ft in (3261.36 mm) |
| Width W/ Outriggers Extended | 14.1 ft in (4295 mm) |
Operational
| Operating Weight | 6900 lb (3129.8 kg) |
| Operating Voltage | 12 V |
