Tadano TMZR303XL
Browse All Tadano or Hydraulic Truck Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 9.35 ft in (2.85 m) |
| Max Height @ Max Raise Angle - No Jib | 21.66 ft in (6.6 m) |
| Min Working Radius | 4.6 ft in (1.41 m) |
| Max Working Radius | 20 ft in (6.1 m) |
| Max Elevating Angle | 76 degrees |
| Number Of Sections | 3 |
| Max Lift Capacity | 7000 lb (3175.15 kg) |
| Swing Speed | 2.5 rpm |
Dimensions
| Transport Length | 9.36 ft in (2850 mm) |
| Transport Width | 2.84 ft in (864 mm) |
| Transport Height | 3.34 ft in (1016 mm) |
| Width W/ Outriggers Extended | 10.43 ft in (3179.07 mm) |
Operational
| Operating Weight | 1910 lb (866.4 kg) |
| Operating Voltage | 12 V |
