Tadano TMZR506XL
Browse All Tadano or Hydraulic Truck Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 12.64 ft in (3.86 m) |
| Max Height @ Max Raise Angle - No Jib | 51.49 ft in (15.7 m) |
| Min Working Radius | 5 ft in (1.53 m) |
| Max Working Radius | 50 ft in (15.24 m) |
| Max Elevating Angle | 78 degrees |
| Number Of Sections | 6 |
| Max Lift Capacity | 7000 lb (3175.15 kg) |
| Swing Speed | 2.5 rpm |
Dimensions
| Transport Length | 12.64 ft in (3852.68 mm) |
| Transport Width | 7.62 ft in (2322 mm) |
| Transport Height | 3.75 ft in (1143 mm) |
| Width W/ Outriggers Extended | 12.44 ft in (3790 mm) |
Operational
| Operating Weight | 4150 lb (1882.5 kg) |
| Operating Voltage | 12 V |
