Terex 820
Browse All Terex or Loader Backhoe Models
Contents:
Backhoe
| Load Height - Std | 11.66 ft in (3553 mm) |
| Reach From Swivel - Std | 18.8 ft in (5730 mm) |
| Dig Depth - Std | 14.67 ft in (4471 mm) |
| Reach At Load Height - Std | 6.55 ft in (1996 mm) |
| Load Height - Ext | 14.87 ft in (4531 mm) |
| Bucket Dig Force - Ext | 11596.32 lb (5260 kg) |
| Bucket Dig Force - Std | 11596.32 lb (5260 kg) |
| Dig Depth - Ext | 19.08 ft in (5815 mm) |
| Reach At Load Height - Ext | 9.6 ft in (2924 mm) |
| Load At Max Lift - Ext | 1790.16 lb (812 kg) |
| Load At Max Lift - Std | 3051.2 lb (1384 kg) |
| Reach From Swivel - Ext | 23.04 ft in (7020 mm) |
Dimensions
| Transport Length | 24.08 ft in (7338 mm) |
| Transport Width | 7.59 ft in (2311 mm) |
| Transport Height | 12.35 ft in (3762 mm) |
| Wheelbase | 6.99 ft in (2130 mm) |
| Ground Clearance | 1.28 ft in (390 mm) |
| Height To Top Of Suspended Cab | 9.09 ft in (2770 mm) |
Loader
| Clearance At Max Dump Height | 8.63 ft in (2629 mm) |
| Reach At Max Dump Height | 2.12 ft in (645 mm) |
| Dig Depth | 6.15 in (156 mm) |
| Bucket Breakout Force | 1069191.35 lb (4756 kN) |
| Bucket Width | 90.99 in (2311 mm) |
| Bucket Capacity | 1.31 yd3 (1 m3) |
| Lift Capacity At Full Height | 7603.75 lb (3449 kg) |
Engine
| Engine Model | 1104C-44T |
| Net Power | 86 hp (64.2 kw) |
| Gross Power | 92 hp (68.7 kw) |
| Power Measured @ | 2200 rpm |
| Torque Measured @ | 1400 rpm |
| Net Max Torque | 291 lb ft (394.6 Nm) |
| Displacement | 269 cu in (4.5 L) |
Operational
| Fuel Capacity | 34.4 gal (130 L) |
| Max Weight | 15763 lb (7150 kg) |
| Hydraulic System Fluid Capacity | 37.8 gal (143 L) |
| Oil System Fluid Capacity | 2.3 gal (8.5 L) |
| Cooling System Fluid Capacity | 4.3 gal (16 L) |
| Transmission Fluid Capacity | 4 gal (15 L) |
| Front Axle Fluid Capacity | 3.4 gal (12.5 L) |
| Rear Axle Fluid Capacity | 4.7 gal (17.5 L) |
| Turning Radius | 12.7 ft in (3850 mm) |
| Tire Size Front - 2wd / 4wd | 12.5x18 |
| Rear Tires Size 2wd/4wd | 16.9x28 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 75 amps |
Transmission
| Transmission Type | 4 speed synchro gearbox |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 4 |
| Max Speed - Forward | 24.9 mph (40 km/h) |
| Max Speed Reverse | 25.5 mph (41 km/h) |
Hydraulic
| Pump Type | twin gear |
| Pump Flow Capacity | 37.6 gal/min (142 L/min) |
| Relief Valve Pressure | 3250 psi (22408 kPa) |
