Doosan DX55
Browse All Doosan or Midi Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 19.36 ft in (5900 mm) |
| Shipping Height Of Unit | 6.52 ft in (1985 mm) |
| Max Cutting Height | 19.07 ft in (5810 mm) |
| Max Loading Height | 13.39 ft in (4080 mm) |
| Max Vertical Wall Digging Depth | 10.21 ft in (3110 mm) |
| Max Digging Depth | 12.42 ft in (3785 mm) |
| Boom/Stick Option (Hex) 1 | Boom 9'10" (3000mm)/Stick 5'3" (1600mm) |
Boom/Stick Option (Hex) 2
| Shipping Length Of Unit | 19.59 ft in (5970 mm) |
| Shipping Height Of Unit | 7.14 ft in (2175 mm) |
| Max Cutting Height | 19.72 ft in (6010 mm) |
| Max Loading Height | 14.05 ft in (4280 mm) |
| Max Digging Depth | 13.41 ft in (4085 mm) |
| Max Vertical Wall Digging Depth | 11.16 ft in (3400 mm) |
| Boom/Stick Option (Hex) 2 | Boom 9'10" (3000mm)/Stick 6'3" (1900mm) |
Dimensions
| Width To Outside Of Tracks | 6.17 ft in (1880 mm) |
| Length Of Track On Ground | 6.53 ft in (1990 mm) |
| Ground Clearance | 1.2 ft in (365 mm) |
| Height To Top Of Cab | 8.21 ft in (2500 mm) |
| Tail Swing Radius | 5.42 ft in (1650 mm) |
Undercarriage
| Shoe Size | 15.75 in (400 mm) |
| Ground Pressure | 4.5 psi (31.03 kPa) |
| Max Travel Speed | 2.49 mph (4 km/h) |
Engine
| Number Of Cylinders | 4 |
| Engine Model | 4TNV98-Z |
| Net Power | 56.4 hp (42.1 kw) |
| Power Measured @ | 2000 rpm |
| Displacement | 202.5 cu in (3.4 L) |
| Max Torque | 183 lb ft (248.1 Nm) |
| Torque Measured @ | 1300 rpm |
Operational
| Operating Weight | 12345.9 lb (5600 kg) |
| Fuel Capacity | 30.4 gal (115 L) |
| Cooling System Fluid Capacity | 2.7 gal (10 L) |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 23.8 gal (90 L) |
| Engine Oil Capacity | 3.1 gal (11.6 L) |
| Alternator Supplied Amperage | 60 amps |
| Hydraulic System Relief Valve Pressure | 2973.3 psi (20500 kPa) |
| Hydraulic Pump Flow Capacity | 29.1 gal/min (110 L/min) |
Swing Mechanism
| Swing Speed | 9.8 rpm |
Buckets
| Reference Bucket Capacity | 0.2 yd3 (0.1 m3) |
