John Deere 80
Browse All John Deere or Midi Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 20.08 ft in (6120 mm) |
| Shipping Height Of Unit | 9.45 ft in (2880 mm) |
Dimensions
| Width To Outside Of Tracks | 7.75 ft in (2360 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2348 |
| Engine Model | 4TNE98-JCF |
| Net Power | 55 hp (41.1 kw) |
| Power Measured @ | 2200 rpm |
| Displacement | 202 cu in (3.4 L) |
| Max Torque | 165 lb ft (223.8 Nm) |
| Torque Measured @ | 1300 rpm |
Operational
| Operating Weight | 15706 lb (7124.2 kg) |
| Fuel Capacity | 35.7 gal (135.2 L) |
| Cooling System Fluid Capacity | 1.6 gal (5.7 L) |
| Hydraulic System Fluid Capacity | 16 gal (60.6 L) |
| Operating Voltage | 24 V |
| Engine Oil Capacity | 2.3 gal (8.5 L) |
| Swing Drive Fluid Capacity | 0.4 gal (1.4 L) |
| Hydraulic System Relief Valve Pressure | 2000 psi (13730 kPa) |
| Hydraulic Pump Flow Capacity | 4.5 gal/min (17.1 L/min) |
Swing Mechanism
| Swing Speed | 10 rpm |
