Hitachi ZX26U-5
Browse All Hitachi or Mini Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Max Cutting Height | 14.7 ft in (4480.57 mm) |
| Max Digging Depth | 8.6 ft in (2621.29 mm) |
| Boom/Stick Option (Hex) 1 | 1.17-m (3 ft. 10 in) Standard Arm - Canopy |
| Max.Dumping Height | 10.6 ft in (3230.88 mm) |
| Max Digging Reach | 15.2 ft in (4632.96 mm) |
| Minimum Swing Radius | 75.6 in (1920 mm) |
Boom/Stick Option (Hex) 2
| Max Cutting Height | 14.1 ft in (4297.68 mm) |
| Max Digging Depth | 8.6 ft in (2621.29 mm) |
| Boom/Stick Option (Hex) 2 | 1.17-m (3 ft. 10 in) Standard Arm - Cab |
| Max Digging Reach | 15.2 ft in (4632.96 mm) |
| Max.Dumping Height | 9.98 ft in (3040 mm) |
| Minimum Swing Radius | 79.14 in (2010 mm) |
Dimensions
| Counterweight Clearance | 1.74 ft in (530 mm) |
| Ground Clearance | 0.99 ft in (300 mm) |
| Tail Swing Radius | 2.63 ft in (800 mm) |
| Blade Width | 4.93 ft in (1500 mm) |
| Overall Height | 7.98 ft in (2430 mm) |
| Track Shoe Width | 0.99 ft in (300 mm) |
Undercarriage
| Cab Rubber Track | 3.8 psi (26.21 kPa) |
| Canopy Rubber Track | 3.6 psi (24.83 kPa) |
| Tracks, Rubber | 11.82 in (300 mm) |
Engine
| Emission Tier Level | EPA Final Tier 4 |
| Engine Model | 3TNV80F |
| Net Power | 20 hp (14.9 kw) |
| Power Measured @ | 2500 rpm |
| Displacement | 77.4 cu in (1.3 L) |
| Alternator | 40 amps |
Capacities
| Engine Oil With Filter | 1 gal (3.7 L) |
| Fuel Tank | 9.1 gal (34.1 L) |
| Hydraulic Tank | 6.4 gal (23.9 L) |
| Cooling System | 0.9 gal (3.2 L) |
Operational
| Blade Height | 12.6 in (320 mm) |
Performance
| Travel Speed Low | 1.9 mph (2.9 km/h) |
| Travel Speed - High | 2.8 mph (4.5 km/h) |
Swing Mechanism
| Swing Brake | Spring applied, hydraulically released, automatic |
| Swing Speed | 9.1 rpm |
Weights
| Cab | 6106.9 lb (2770 kg) |
| Canopy | 5776.2 lb (2620 kg) |
Buckets
| Bucket Digging Force - Sae | 4993.1 lb (22.3 kN) |
| Arm Digging Force | 3410.4 lb (15.2 kN) |
Hydraulic
| Pump Piston | 19.1 gal/min (72 L/min) |
| Gear Pump | 4.4 gal/min (16.3 L/min) |
Hydraulic System
| Auxiliary Hydraulic Flow | 12.2 gal/min (46.2 L/min) |
Boom
| Arm Left | 70 degrees |
| Arm Right | 60 degrees |
