Komatsu PC12R-8
Browse All Komatsu or Mini Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 11.47 ft in (3495 mm) |
| Max Cutting Height | 10.95 ft in (3335 mm) |
| Shipping Height Of Unit | 7.35 ft in (2240 mm) |
| Max Loading Height | 7.67 ft in (2335 mm) |
| Max Reach Along Ground | 11.24 ft in (3425 mm) |
| Max Vertical Wall Digging Depth | 4.94 ft in (1505 mm) |
| Max Digging Depth | 6.24 ft in (1900 mm) |
| Boom/Stick Option (Hex) 1 | Boom 5'4" (1620mm)/Stick 2'11" (880mm) |
Boom/Stick Option (Hex) 2
| Max Cutting Height | 11.54 ft in (3515 mm) |
| Shipping Length Of Unit | 11.96 ft in (3645 mm) |
| Max Loading Height | 8.27 ft in (2520 mm) |
| Shipping Height Of Unit | 7.35 ft in (2240 mm) |
| Max Reach Along Ground | 12.11 ft in (3690 mm) |
| Max Vertical Wall Digging Depth | 5.8 ft in (1765 mm) |
| Max Digging Depth | 7.16 ft in (2180 mm) |
| Boom/Stick Option (Hex) 2 | Boom 5'4" (1620mm)/Stick 3'8" (1130mm) |
Dimensions
| Width To Outside Of Tracks | 3.29 ft in (1000 mm) |
| Length Of Track On Ground | 3.35 ft in (1020 mm) |
| Ground Clearance | 0.68 ft in (205 mm) |
| Height To Top Of Cab | 7.35 ft in (2240 mm) |
| Tail Swing Radius | 3.52 ft in (1070 mm) |
| Removal Counterweight Clearance | 1.15 ft in (350 mm) |
Undercarriage
| Shoe Size | 7.88 in (200 mm) |
| Track Gauge | 2.63 ft in (800 mm) |
| Max Travel Speed | 2.49 mph (4 km/h) |
| Ground Pressure | 4.1 psi (28.27 kPa) |
Engine
| Engine Make | 2238 |
| Engine Model | 3D68E |
| Gross Power | 13.9 hp (10.3 kw) |
| Power Measured @ | 2450 rpm |
| Displacement | 47.9 cu in (0.8 L) |
Operational
| Operating Weight | 2866.1 lb (1300 kg) |
| Fuel Capacity | 5.3 gal (20 L) |
| Hydraulic System Fluid Capacity | 3.5 gal (13 L) |
| Hydraulic System Relief Valve Pressure | 2700 psi (18615.9 kPa) |
| Hydraulic Pump Flow Capacity | 9.9 gal/min (37.2 L/min) |
Swing Mechanism
| Swing Speed | 8.7 rpm |
Buckets
| Reference Bucket Capacity | 0.1 yd3 (0.1 m3) |
| Minimum Bucket Capacity | 0.1 yd3 (0.1 m3) |
| Maximum Bucket Capacity | 0.1 yd3 (0.1 m3) |
