Case 845 DHP
Browse All Case or Motor Grader Models
Contents:
Dimensions
| Overall Length | 28 ft in (8534 mm) |
| Width Over Tires | 8.25 ft in (2510 mm) |
| Wheelbase | 20.43 ft in (6219 mm) |
| Rear Ground Clearance | 1.25 ft in (380 mm) |
| Tandem Axle Wheelbase | 5.17 ft in (1594 mm) |
| Front Ground Clearance | 2.04 ft in (622 mm) |
| Blade Base | 8.42 ft in (2562 mm) |
| Height To Top Of Isomount Cab | 10.92 ft in (3340 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2347 |
| Engine Model | QSB 6.7, Tier III certified electronic controlled |
| Power Measured @ | 2200 rpm |
| Torque Measured @ | 1500 rpm |
| Max Power | 160 hp (119.4 kw) |
| Net Power Gears 7-8 | 160 hp (119 kw) |
| Net Torque Gears 7-8 | 550 lb ft (746 Nm) |
| Displacement | 411 cu in (6.7 L) |
| Aspiration | turbocharged and air to air aftercooled |
Operational
| Std Operation Weight - Front Axle | 8155 lb (3707 kg) |
| Hydraulic System Fluid Capacity | 47.5 gal (180 L) |
| Std Operation Weight - Rear Axle | 21621 lb (9828 kg) |
| Std Operation Weight - Total | 29777 lb (13535 kg) |
| Oil System Fluid Capacity | 4.3 gal (16.3 L) |
| Fuel Capacity | 90 gal (340.7 L) |
| Cooling System Fluid Capacity | 10.5 gal (40 L) |
| Transmission Fluid Capacity | 6.6 gal (25 L) |
| Rear Diff/Final Drive Fluid Capacity | 3.2 gal (12 L) |
| Circle Gearbox Fluid Capacity | 0.8 gal (2.8 L) |
| Tandem Case Fluid Capacity (Each) | 7.6 gal (28.7 L) |
| Tire Size | 14.0 x 24 12PR TL G2 Firestone |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 amps |
Steering
| Articulation Angle | 25 degrees |
| Turning Radius | 23.8 ft in (7.3 m) |
Transmission
| Transmission Type | Direct drive countershaft powershift w/ electronic shift control and inching pedal |
| Number Of Gears - Forward | 8 |
| Number Of Gears - Reverse | 4 |
| Max Speed - Forward | 26.6 mph (42.9 km/h) |
| Max Speed - Reverse | 17.7 mph (28.5 km/h) |
Front Axle
| Wheel Lean | 17.5 degrees |
| Oscillation - Total | 19 degrees |
Moldboard
| Moldboard Width | 12 ft in (3658 mm) |
| Moldboard Height | 22 in (559 mm) |
| Moldboard Thickness | 0.9 in (22.2 mm) |
| Max Depth Of Cut | 28 in (711.2 mm) |
| Side Shift Left | 21 in (533 mm) |
| Side Shift Right | 27 in (686 mm) |
Hydraulic System
| Pump Type | Closed center, load sensing, gear pump. |
| Pump Flow | 50.5 gal/min (191.5 L/min) |
Circle
| Diameter | 69 in (1752.6 mm) |
| Rotation | 360 degrees |
| Max Lift Above Ground | 17.5 in (444.5 mm) |
