Tata Hitachi TG14
Browse All Tata Hitachi or Motor Grader Models
Contents:
Dimensions
| Overall Length | 27.86 ft in (8490 mm) |
| Width Over Tires | 8.13 ft in (2477 mm) |
| Wheelbase | 20.41 ft in (6219 mm) |
| Tandem Axle Wheelbase | 5.06 ft in (1542 mm) |
| Blade Base | 12.01 ft in (3658 mm) |
| Height To Top Of Isomount Cab | 10.93 ft in (3330 mm) |
Engine
| Net Power Gear 4-6 | 140 hp (104.4 kw) |
| Engine Make | 2347 |
| Engine Model | 6 A 5.9-C |
| Max Power | 140 hp (104.4 kw) |
| Displacement | 358.9 cu in (5.9 L) |
| Aspiration | Turbocharged |
Operational
| Std Operation Weight - Front Axle | 10824.7 lb (4910 kg) |
| Hydraulic System Fluid Capacity | 52.9 gal (200 L) |
| Std Operation Weight - Rear Axle | 20128.3 lb (9130 kg) |
| Std Operation Weight - Total | 30953 lb (14040 kg) |
| Fuel Capacity | 76.7 gal (290 L) |
| Cooling System Fluid Capacity | 11.9 gal (45 L) |
| Transmission Fluid Capacity | 5.6 gal (21 L) |
| Rear Diff/Final Drive Fluid Capacity | 5.6 gal (21 L) |
| Circle Gearbox Fluid Capacity | 2.4 gal (9 L) |
| Tandem Case Fluid Capacity (Each) | 11.4 gal (43 L) |
| Tire Size | 13x24 (12PR) |
Steering
| Turning Radius | 24 ft in (7.3 m) |
Transmission
| Transmission Type | ZF ERGOPOWER, automatic gear shift |
| Number Of Gears - Forward | 6 |
| Number Of Gears - Reverse | 3 |
| Max Speed - Forward | 24.9 mph (40 km/h) |
| Max Speed - Reverse | 17.9 mph (28.8 km/h) |
Front Axle
| Wheel Lean | 48 degrees |
| Oscillation - Total | 19 degrees |
| Ground Clearance | 2 ft in (597 mm) |
Hydraulic System
| Pump Type | fully hydraulic with load sensing gear pump and closed centre COMPCHECK control valve |
| Pump Flow | 52.9 gal/min (200 L/min) |
| Relief Valve Pressure | 2755.8 psi (19000 kPa) |
