Terex TG150
Browse All Terex or Motor Grader Models
Contents:
Dimensions
| Overall Length | 30.85 ft in (9402 mm) |
| Width Over Tires | 7.94 ft in (2419 mm) |
| Wheelbase | 18.63 ft in (5676 mm) |
| Rear Ground Clearance | 1.56 ft in (474 mm) |
| Tandem Axle Wheelbase | 5.11 ft in (1555 mm) |
| Front Ground Clearance | 1.8 ft in (546 mm) |
| Blade Base | 7.24 ft in (2204 mm) |
| Height To Top Of Isomount Cab | 10.75 ft in (3276 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2347 |
| Power Measured @ | 2200 rpm |
| Net Power Gear 5-6 | 163 hp (121.6 kw) |
| Max Power | 163 hp (121.6 kw) |
| Displacement | 366.2 cu in (6 L) |
| Aspiration | turbocharged |
Operational
| Std Operation Weight - Front Axle | 9479.9 lb (4300 kg) |
| Hydraulic System Fluid Capacity | 39.7 gal (150 L) |
| Std Operation Weight - Rear Axle | 22487.2 lb (10200 kg) |
| Std Operation Weight - Total | 31967.1 lb (14500 kg) |
| Fuel Capacity | 81.9 gal (310 L) |
| Cooling System Fluid Capacity | 11.9 gal (45 L) |
| Transmission Fluid Capacity | 4.8 gal (18 L) |
| Rear Diff/Final Drive Fluid Capacity | 4 gal (15 L) |
| Circle Gearbox Fluid Capacity | 1.6 gal (6 L) |
| Tandem Case Fluid Capacity (Each) | 10.6 gal (40 L) |
| Tire Size | 13.00 -24 TG SGG-2A Goodyear |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 amps |
Steering
| Articulation Angle | 45 degrees |
| Turning Radius | 22.7 ft in (6.9 m) |
Transmission
| Transmission Type | Auto Power Shift Tansmission With torque Converter |
| Number Of Gears - Forward | 6 |
| Number Of Gears - Reverse | 3 |
| Max Speed - Forward | 24.9 mph (40 km/h) |
| Max Speed - Reverse | 15.6 mph (25 km/h) |
Front Axle
| Wheel Lean | 17 degrees |
| Oscillation - Total | 15 degrees |
| Ground Clearance | 1.8 ft in (546 mm) |
Moldboard
| Moldboard Width | 12.1 ft in (3660 mm) |
| Moldboard Height | 22.9 in (580 mm) |
| Moldboard Thickness | 0.8 in (20 mm) |
| Side Shift Left | 49.3 in (1250 mm) |
| Side Shift Right | 49.3 in (1250 mm) |
| Blade Pull At Max Weight | 17994 lb (8162 kg) |
Hydraulic System
| Pump Type | Axial Piston Pump |
| Pump Flow | 26.2 gal/min (99 L/min) |
| Relief Valve Pressure | 2669 psi (18402.1 kPa) |
Circle
| Diameter | 53.1 in (1348 mm) |
| Max Reach Outside Tires - Left | 98.5 in (2500 mm) |
| Max Reach Outside Tires - Right | 125.2 in (3180 mm) |
| Max Lift Above Ground | 18.9 in (480 mm) |
