Toyota SV2032E
Browse All Toyota or Scissor Lift Models
Contents:
Dimensions
| Overall Length | 90.56 in (2300 mm) |
| Wheelbase | 5.91 ft in (1800 mm) |
| Overall Width | 2.66 ft in (810 mm) |
| Ground Clearance | 5.12 in (130 mm) |
| Gradeability | 25 % |
| Ground Pressure | 81 psi (558.48 kPa) |
| Overall Height | 7.27 ft in (2215.9 mm) |
| Turning Radius - Outside | 7.39 ft in (2250 mm) |
Platform
| Max Platform Height | 20.02 ft in (6100 mm) |
| Overall Height (Stowed, Guardrail Folded) | 6.13 ft in (1.87 m) |
| Overall Length (Stowed , Guardrail Folded) | 8.2 ft in (2.5 m) |
| Lower Time | 40 sec |
| Platform Capacity - Extension | 250 lb (113.4 kg) |
| Platform Extension Length | 35.4 in (899.16 mm) |
| Platform Height - Elevated | 20 ft in (6.1 m) |
| Platform Height - Lowered | 43.1 ft in (13.14 m) |
| Platform Inner Length | 86.62 in (2200 mm) |
| Platform Inner Width | 26.78 in (680 mm) |
| Platform Railing Height | 43.7 ft in (13.32 m) |
| Scissor Link Stages | 3 |
| Max Platform Weight Capacity | 800 lb (362.88 kg) |
| Lift Time | 28 sec |
| Max Working Height | 26 ft in (7924.8 mm) |
Engine
| System Voltage | 24 V |
Operational
| Tire Fill/Type | Solid |
Performance
| Drive System | Brushless Dual AC Motors |
| Travel Speed (Maximum) | 0.5 mph (0.9 km/h) |
| Travel Speed (Minimum) | 2.8 mph (4.6 km/h) |
