Tata Hitachi ZAXIS450H
Browse All Tata Hitachi or Shovel Models
Contents:
Backhoe Boom / Stick 1
| Max Dig Depth | 19.43 ft in (5920 mm) |
| Max Vertical Wall Dig Depth | 13.72 ft in (4180 mm) |
| Max Cutting Height | 34.52 ft in (10520 mm) |
| Max Dump Height | 23.59 ft in (7190 mm) |
| Arm Crowd Force | _ - (271 Nm) |
| Backhoe Boom / Stick | Boom 6300mm/Stick 2500mm |
| Max Reach On Ground | 33.6 ft in (10240 mm) |
Backhoe Boom / Stick 2
| Max Cutting Height | 34.95 ft in (10650 mm) |
| Max Dump Height | 23.99 ft in (7310 mm) |
| Max Vertical Wall Dig Depth | 15.03 ft in (4580 mm) |
| Max Dig Depth | 20.54 ft in (6260 mm) |
| Backhoe Boom / Stick | Boom 6300mm/Stick 2900mm |
| Max Reach On Ground | 34.55 ft in (10530 mm) |
| Arm Crowd Force | _ - (232 Nm) |
Backhoe Boom / Stick 3
| Max Cutting Height | 32.91 ft in (10030 mm) |
| Max Dump Height | 22.87 ft in (6970 mm) |
| Max Vertical Wall Dig Depth | 13.69 ft in (4170 mm) |
| Max Dig Depth | 24.05 ft in (7330 mm) |
| Max Reach On Ground | 36.49 ft in (11120 mm) |
| Backhoe Boom / Stick | Boom 7000mm/Stick 2900mm |
| Arm Crowd Force | _ - (234 Nm) |
Backhoe Boom / Stick 4
| Max Cutting Height | 35.93 ft in (10950 mm) |
| Max Dump Height | 24.74 ft in (7540 mm) |
| Max Vertical Wall Dig Depth | 22.25 ft in (6780 mm) |
| Max Dig Depth | 25.89 ft in (7890 mm) |
| Arm Crowd Force | _ - (202 Nm) |
| Backhoe Boom / Stick | Boom 7000mm/Stick 3400mm |
| Max Reach On Ground | 38.92 ft in (11860 mm) |
Dimensions
| Width Over Tracks | _ - (3340 mm) |
| Length Of Track On Ground | 13.29 ft in (4050 mm) |
| Height To Top Of Cab | 10.67 ft in (3250 mm) |
| Ground Clearance | 1.63 in (496 mm) |
| Length Of Tracks | 16.57 ft in (5050 mm) |
| Upper Structure Ground Clearance | 4.04 ft in (1230 mm) |
| Height Of Tracks | _ - (1140 mm) |
Loading Shovel
| Max Dig Reach | 28.75 ft in (8760 mm) |
| Max Dump Height | 24.18 ft in (7370 mm) |
| Max Cutting Height | 32.62 ft in (9940 mm) |
| Max Dig Depth | 13.98 ft in (4260 mm) |
| Arm Crowd Force | _ - (271 Nm) |
Undercarriage
| Loading Shovel Shoe Width | 23.63 in (600 mm) |
| Backhoe Operating Weight - Shoe 1 | 100971.73 lb (45800 kg) |
| Number Of Lower Rollers | 8 |
| Number Of Track Shoes Per Side | 47 |
| Number Of Upper Rollers | 2 |
| Loading Shovel Operating Weight | 103176.35 lb (46800 kg) |
| Backhoe Ground Pressure - Shoe 1 | 12.04 psi (83 kPa) |
| Loading Shovel Ground Pressure | 12.33 psi (85 kPa) |
| Max Travel Speed | 3.42 mph (5.5 km/h) |
| Backhoe Shoe Width 1 | 23.63 in (600 mm) |
Engine
| Engine Make | 2353 |
| Engine Model | AA-6WG 1TQA |
| Net Power | 315.2 hp (235 kw) |
| Aspiration | turbocharged |
| Displacement | 957 cu in (15.7 L) |
Operational
| Fuel Capacity | 171.8 gal (650 L) |
| Cooling System Fluid Capacity | 16.2 gal (61 L) |
| Engine Oil Capacity | 14.6 gal (55 L) |
| Hydraulic System Fluid Capacity | 21.2 gal (80 L) |
| Swing Speed | 9 rpm |
| Operating Voltage | 24 V |
