Terex RH30FHDRLC
Contents:
Backhoe Boom / Stick 1
| Max Dig Depth | 21.66 ft in (6600 mm) |
| Max Cutting Height | 32.49 ft in (9900 mm) |
| Max Dump Height | 22.31 ft in (6800 mm) |
| Max Reach On Ground | 36.42 ft in (11100 mm) |
| Backhoe Boom / Stick | Boom 6850mm/Stick 2600mm |
Backhoe Boom / Stick 2
| Max Cutting Height | 39.05 ft in (11900 mm) |
| Max Dump Height | 27.24 ft in (8300 mm) |
| Max Dig Depth | 22.97 ft in (7000 mm) |
| Max Reach On Ground | 40.36 ft in (12300 mm) |
| Backhoe Boom / Stick | Boom 7250mm/Stick2900mm |
Backhoe Boom / Stick 3
| Max Cutting Height | 40.03 ft in (12200 mm) |
| Max Dump Height | 27.89 ft in (8500 mm) |
| Max Dig Depth | 24.28 ft in (7400 mm) |
| Backhoe Boom / Stick | Boom 7250mm/Stick 3400mm |
| Max Reach On Ground | 41.67 ft in (12700 mm) |
Backhoe Boom / Stick 4
| Max Cutting Height | 41.02 ft in (12500 mm) |
| Max Dump Height | 28.88 ft in (8800 mm) |
| Max Dig Depth | 26.58 ft in (8100 mm) |
| Backhoe Boom / Stick | Boom 7250mm/Stick 4100 mm |
| Max Reach On Ground | 43.64 ft in (13300 mm) |
Dimensions
| Width Over Tracks | 13.46 ft in (4100 mm) |
| Length Of Track On Ground | 16.87 ft in (5140 mm) |
| Height To Top Of Cab | 13.1 ft in (3990 mm) |
| Ground Clearance | 35.44 in (900 mm) |
| Upper Structure Ground Clearance | 5.17 ft in (1575 mm) |
| Length Of Tracks | 20.81 ft in (6340 mm) |
Loading Shovel
| Max Dig Reach | 31.5 ft in (9600 mm) |
| Max Dump Height | 21.99 ft in (6700 mm) |
| Max Cutting Height | 28.88 ft in (8800 mm) |
| Max Dig Depth | 7.55 ft in (2300 mm) |
| Height To Top Of Boom - Shovel | 17.07 ft in (5200 mm) |
Undercarriage
| Tail Swing Radius | 13.52 ft in (4120 mm) |
| Loading Shovel Shoe Width | 23.63 in (600 mm) |
| Track Gauge | 11.49 ft in (3500 mm) |
| Number Of Upper Rollers | 3 |
| Backhoe Ground Pressure - Shoe 1 | 18.8 psi (129.63 kPa) |
| Loading Shovel Operating Weight | 188274.76 lb (85400 kg) |
| Loading Shovel Ground Pressure | 20.3 psi (139.97 kPa) |
| Backhoe Shoe Width 3 | 35.44 in (900 mm) |
| Backhoe Shoe Width 2 | 29.53 in (750 mm) |
| Backhoe Shoe Width 1 | 23.63 in (600 mm) |
| Backhoe Operating Weight - Shoe 3 | 199077.41 lb (90300 kg) |
| Backhoe Operating Weight - Shoe 2 | 196652.33 lb (89200 kg) |
| Backhoe Operating Weight - Shoe 1 | 194227.25 lb (88100 kg) |
| Backhoe Ground Pressure - Shoe 3 | 12.8 psi (88.26 kPa) |
| Backhoe Ground Pressure - Shoe 2 | 15.2 psi (104.81 kPa) |
| Max Travel Speed | 2.93 mph (4.7 km/h) |
| Number Of Lower Rollers | 9 |
Engine
| Engine Make | 2347 |
| Engine Model | QSX 15 |
| Net Power | 489 hp (364.7 kw) |
| Gross Power | 509 hp (379.6 kw) |
| Power Measured @ | 1800 rpm |
Operational
| Fuel Capacity | 277.4 gal (1050 L) |
| Hydraulic System Fluid Capacity | 369.9 gal (1400 L) |
| Swing Speed | 5.8 rpm |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 175 amps |
Buckets
| Minimum Bucket Capacity | 4.6 yd3 (3.6 m3) |
| Maximum Bucket Capacity | 7.2 yd3 (5.6 m3) |
