Gehl 5240E
Browse All Gehl or Skid Steer Loader Models
Contents:
Dimensions
| Length With Bucket | 10.53 ft in (3208 mm) |
| Width Over Tires | 5.17 ft in (1575 mm) |
| Ground Clearance | 6.23 in (158 mm) |
| Height To Top Of Cab | 6.5 ft in (1981 mm) |
| Wheelbase | 3.46 ft in (1054 mm) |
| Length W/O Bucket | 7.78 ft in (2370 mm) |
| Clearance At Max Lift And Dump | 7.46 ft in (2273 mm) |
| Reach At Max Lift And Dump | 25 in (635 mm) |
| Turning Radius From Center - Machine Rear | 61.5 in (1562 mm) |
| Turning Radius From Center - Inc Bucket | 75.99 in (1930 mm) |
Engine
| Engine Make | 2349 |
| Engine Model | TD2009 |
| Net Power | 62 hp (46.3 kw) |
| Power Measured @ | 2500 rpm |
| Aspiration | Turbocharged |
Operational
| Operational Weight | 6860.8 lb (3112 kg) |
| Hydraulic System Fluid Capacity | 11.9 gal (45 L) |
| Tire Size | 10.00x16.5 HD |
Loader
| Operating Load Rating | 1900.4 lb (862 kg) |
| Tipping Angle | 3800.8 degrees |
Hydraulic
| Pump Flow Capacity | 19.1 gal/min (72 L/min) |
