Komatsu SK05J-2
Browse All Komatsu or Skid Steer Loader Models
Contents:
Dimensions
| Length With Bucket | 9.06 ft in (2760 mm) |
| Width Over Tires | 3.99 ft in (1214 mm) |
| Ground Clearance | 7.68 in (195 mm) |
| Height To Top Of Cab | 6.14 ft in (1870 mm) |
| Wheelbase | 2.63 ft in (800 mm) |
| Clearance At Max Lift And Dump | 7.09 ft in (2160 mm) |
| Reach At Max Lift And Dump | 18.12 in (460 mm) |
| Turning Radius From Center - Machine Rear | 53.47 in (1358 mm) |
| Turning Radius From Center - Inc Bucket | 63.67 in (1617 mm) |
Engine
| Number Of Cylinders | 3 |
| Engine Make | 2238 |
| Engine Model | 3D84E-1FC |
| Gross Power | 36 hp (26.9 kw) |
| Net Power | 30.9 hp (23 kw) |
| Power Measured @ | 2800 rpm |
| Displacement | 87.3 cu in (1.5 L) |
Operational
| Operational Weight | 3880.2 lb (1760 kg) |
| Fuel Capacity | 12.7 gal (48 L) |
| Engine Oil Fluid Capacity | 2 gal (7.5 L) |
| Max Speed | 5.8 mph (9.2 km/h) |
| Hydraulic System Fluid Capacity | 4 gal (15 L) |
| Tire Size | 27- 8.50 x 15 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 amps |
Loader
| Breakout Force | 2786.7 lb (1264 kg) |
| Operating Load Rating | 956.9 lb (434 kg) |
| Tipping Angle | 1874 degrees |
| Bucket Capacity | 0.1 yd3 (0.1 m3) |
Hydraulic
| Pump Type | gear pump |
| Pump Flow Capacity | 8.5 gal/min (32 L/min) |
| Relief Valve Pressure | 2030.6 psi (14000 kPa) |
