JCB 160
Browse All JCB or Skid Steer Loader Models
Contents:
Dimensions
| Length With Bucket | 10.54 ft in (3210 mm) |
| Width Over Tires | 4.5 ft in (1370 mm) |
| Height To Top Of Cab | 6.34 ft in (1930 mm) |
| Wheelbase | 3.22 ft in (980 mm) |
| Length W/O Bucket | 7.68 ft in (2340 mm) |
| Clearance At Max Lift And Dump | 7.09 ft in (2160 mm) |
| Reach At Max Lift And Dump | 22.45 in (570 mm) |
| Turning Radius From Center - Machine Rear | 62.21 in (1580 mm) |
| Turning Radius From Center - Inc Bucket | 73.63 in (1870 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Model | 404C-22 |
| Gross Power | 47 hp (35.1 kw) |
| Net Power | 44 hp (32.9 kw) |
| Power Measured @ | 2600 rpm |
| Aspiration | Naturally aspirated |
| Displacement | 134.3 cu in (2.2 L) |
Operational
| Operational Weight | 5310 lb (2408.6 kg) |
| Fuel Capacity | 21 gal (79.5 L) |
| Cooling System Fluid Capacity | 2.1 gal (8 L) |
| Engine Oil Fluid Capacity | 2.5 gal (9.5 L) |
| Hydraulic System Fluid Capacity | 7.9 gal (30 L) |
| Max Speed | 6.3 mph (10.2 km/h) |
| Chain Box Fluid Capacity - Each Side | 4.5 gal (17.1 L) |
| Tire Size | 7.00 x 15 - 6 pr |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 55 amps |
Loader
| Breakout Force | 2998 lb (1359.9 kg) |
| Operating Load Rating | 1322.8 lb (600 kg) |
| Tipping Angle | 2645.6 degrees |
| Bucket Capacity | 0.4 yd3 (0.3 m3) |
Hydraulic
| Pump Type | Hydrostatic drive pumps |
| Pump Flow Capacity | 14.5 gal/min (54.9 L/min) |
| Relief Valve Pressure | 2683 psi (18498.7 kPa) |
