New Holland L216
Browse All New Holland or Skid Steer Loader Models
Contents:
Dimensions
| Ground Clearance | 7.01 in (178 mm) |
| Wheelbase | 3.09 ft in (941 mm) |
| Bucket Hinge Pin | 112.01 in (2845 mm) |
| Dump Angle | 40 degrees |
| Angle Of Departure | 22 degrees |
| Rollback, Bucket At Full Height | 95 degrees |
| Rollback, Bucket On Ground | 26 degrees |
| Top Of Rops | 75.56 in (1919 mm) |
| Overall Width | 4.99 ft in (1518 mm) |
| Bottom Of Level Bucket, Fully Raised | 105.6 in (2682 mm) |
Engine
| Air Intake | Turbocharged with external EGR |
| Fuel Injection | Indirect |
| Horsepower Per Sae J1349 Net | 57 hp (42.6 kw) |
| Horsepower Per Sae J1349 Gross | 60 hp (44.8 kw) |
| Engine Model | N844LT |
| Rated Speed | 2800 rpm |
| Peak Torque | 138.7 lb ft (188 Nm) |
| Displacement | 135.3 cu in (2.3 L) |
| Bore | 3.4 in (84 mm) |
| Stroke | 4 in (100 mm) |
Capacities
| Engine Oil With Filter | 1.9 gal (7.1 L) |
| Chain Tanks | 1.7 gal (6.3 L) |
| Fuel Tank | 16 gal (60.5 L) |
Performance
| Tipping Load | 3207.8 lb (1455 kg) |
| Operating Weight | 5522.6 lb (2505 kg) |
| Breakout Force, Bucket Cylinder | 5260.6 lb (23.4 kN) |
| Breakout Force, Lift Cylinder | 3304.7 lb (14.7 kN) |
| Rated Operating Load, 50% Tip | 1598.4 lb (725 kg) |
Power Train
| Travel Speed, Low Range | 7.4 mph (12 km/h) |
Weights
| Operating Weight | 5522.6 lb (2505 kg) |
| Shipping | 5225 lb (2370 kg) |
Hydraulic System
| Standard Pump Flow | 18.4 gal/min (69.7 L/min) |
| Relief Valve Pressure | 3046 psi (21001.5 kPa) |
