Ranger F67 Cable
Contents:
Dimensions
| Height To Top Of Cab | 10.38 ft in (3162 mm) |
| Ground Clearance | 1.48 ft in (450 mm) |
| Wheelbase | 10.71 ft in (3264 mm) |
| Drum Diameter | 12 in (304.8 mm) |
| Drum Capacity At Cable Width | 314.97 ft in (96 m) |
| Cable Width | 0.62 in (15.75 mm) |
| Max Blade Height | 49.38 in (1254 mm) |
| Max Line Pull - Bare Drum | 33271.73 lb (148 kN) |
| Max Line Speed | 303 ft/min (92.36 m/min) |
| Blade Width | 7.01 ft in (2134 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2347 |
| Engine Model | 6BTA5.9 |
| Gross Power | 132 hp (98.5 kw) |
| Net Power | 118 hp (88 kw) |
| Power Measured @ | 2500 rpm |
| Peak Torque | 447 lb ft (606.1 Nm) |
| Torque Measured @ | 1500 rpm |
| Displacement | 358.9 cu in (5.9 L) |
Operational
| Operating Weight | 26521.7 lb (12030 kg) |
| Fuel Capacity | 48.1 gal (182 L) |
| Hydraulic System Fluid Capacity | 19.3 gal (73 L) |
| Operational Voltage | 12 V |
| Alternator Supplied Amperage | 65 amps |
| Axle Oscillation | 24 degrees |
| Tire Size | 23.1-26 |
Transmission
| Transmission Type | clark model R-28 |
| Number Of Forward Gears | 3 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 16.3 mph (26.3 km/h) |
| Max Speed - Reverse | 16.3 mph (26.3 km/h) |
Hydraulic
| Pump Type | gear type |
| Pump Flow | 36.8 gal/min (139.4 L/min) |
