Gehl CT7-23 Turbo
Browse All Gehl or Telescopic Forklift Models
Contents:
Dimensions
| Ground Clearance | 17.92 ft in (455 mm) |
| Width Over Tires | 7.55 ft in (2300 mm) |
| Overall Height | 7.55 ft in (2300 mm) |
| Turning Radius Outside Tires | 12.14 ft in (3700 mm) |
Lift
| Max Lift Height | 22.64 ft in (6900 mm) |
| Max Forward Reach | 13.92 ft in (4240 mm) |
| Max Load At Max Reach | 2000 lb (907.19 kg) |
| Max Load At Max Height | 6000 lb (2721.56 kg) |
| Max Lift Capacity | 7000 lb (3175.15 kg) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2351 |
| Engine Model | 1104-C44T |
| Gross Power | 101 hp (75.4 kw) |
| Power Measured @ | 1400 rpm |
| Max Torque | 304 lb ft (412.2 Nm) |
| Displacement | 268 cu in (4.4 L) |
| Aspiration | turbocharged |
Operational
| Operating Weight | 16016 lb (7264.8 kg) |
| Fuel Capacity | 31.8 gal (120 L) |
| Hydraulic System Fluid Capacity | 33 gal (124.9 L) |
| Drawbar Pull | 19334 lb (8769.8 kg) |
| Tire Size | 17.5 LR x 24 |
Transmission
| Transmission Type | torque converter |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 4 |
| Max Speed - Forward | 18 mph (29 km/h) |
| Max Speed - Reverse | 21 mph (33.8 km/h) |
Hydraulic
| Pump Type | variable displacement piston |
| Pump Flow Capacity | 28 gal/min (106 L/min) |
| Relief Valve Pressure | 3916 psi (26999.9 kPa) |
