Massey Ferguson MF 415N
Browse All Massey Ferguson or Utility Tractor Models
Contents:
Dimensions
| Overall Length | 11.39 in (3470 mm) |
| Wheelbase | 6.6 ft in (2010 mm) |
| Overall Width | 5.06 ft in (1540 mm) |
| Height With Out Rops | 5.16 ft in (1570 mm) |
Engine
| Engine Make | 2351 |
| Engine Model | AD3.152 |
| Gross Power | 46 hp (34.4 kw) |
| Pto Power | 39.7 hp (29.7 kw) |
| Power Measured @ | 2250 rpm |
| Max Torque | 133.5 lb ft (181 Nm) |
| Torque Measured @ | 1350 rpm |
| Displacement | 152.6 cu in (2.5 L) |
| Aspiration | natural |
Operational
| Operating Weight | 4475.4 lb (2030 kg) |
| Fuel Capacity | 15.1 gal (57 L) |
| Hydraulic System Fluid Capacity | 11.1 gal (42 L) |
| 3 Point Hitch Lift Capacity @ 24 Inches | 4629.8 lb (2100 kg) |
| Turning Radius | 10.5 ft in (3180 mm) |
| Tire Size Front - 2wd / 4wd | 6.00-16 |
| Rear Tires Size 2wd/4wd | 14.9-24 |
| Alternator Supplied Amperage | 55 amps |
Transmission
| Transmission Type | 8 speed sliding spur |
| Number Of Forward Gears | 8 |
| Number Of Reverse Gears | 2 |
Hydraulic System
| Relief Valve Setting | 3045.8 psi (21000 kPa) |
| Pump Flow Capacity | 4.5 gal/min (17 L/min) |
