Caterpillar CB434D
Browse All Caterpillar or Vibratory Smooth Drum Roller Models
Contents:
Dimensions
| Overall Length | 165 in (4191 mm) |
| Overall Width | 5.5 ft in (1676.4 mm) |
| Height To Top Of Cab | 10.03 ft in (3055 mm) |
| Wheelbase | 10.18 in (3100 mm) |
| Ground Clearance | 10.04 in (255 mm) |
| Maximum Machine Height | 119 in (3022.6 mm) |
| Drum Width | 59 in (1498.6 mm) |
| Wheel Base | 10.17 ft in (0.26 m) |
| Height - Steering Wheel | 89 in (2260.6 mm) |
| Drum Diameter | 42 in (1066.8 mm) |
Operating Specifications
| Ground Clearance | 0.84 ft in (0.03 m) |
| Curb Clearance | 28 in (711.2 mm) |
| Standard Compaction Width | 59 in (1498.6 mm) |
| Static Linear Load | 138 lb (62.6 kg) |
| Travel Speed - Maximum | 7 mph (11.27 km/h) |
| Turning Radius - Inside Drum Edge | 138 in (3505.2 mm) |
Engine
| Engine Make | 2236 |
| Engine Model | 3054C |
| Gross Power | 83 hp (61.9 kw) |
| Net Power | 79.2 hp (59 kw) |
| Displacement | 268.6 cu in (4.4 L) |
| Engine Model | 3054C |
Operational
| Operating Weight | 16689 lb (7570 kg) |
| Fuel Capacity | 34.9 gal (132 L) |
| Cooling System Fluid Capacity | 4.8 gal (18 L) |
| Engine Oil Capacity | 2.4 gal (9 L) |
| Hydraulic System Fluid Capacity | 13.3 gal (50 L) |
| Max Speed | 7.3 mph (11.6 km/h) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 80 amps |
Drum
| Drum Width | 59.1 in (1500 mm) |
| Drum Diameter | 43.4 in (1100 mm) |
| Static Linear Load | 358.5 lb/in (25.2 kg/cm) |
| Vibration Frequency 1 | 53 Hz |
| Nominal Amplitude - High | 0.1 in (0.7 mm) |
| Nominal Amplitude - Med High | 0.1 in (0.6 mm) |
| Nominal Amplitude - Med | 0.1 in (0.5 mm) |
| Nominal Amplitude - Med Low | 0.1 in (0.4 mm) |
| Vibration Frequency 2 | 70 Hz |
| Nominal Amplitude - Low | 0.1 in (0.3 mm) |
| Centrifugal Force - High | 17535.1 lb (78 kN) |
| Centrifugal Force - Med High | 14837.4 lb (66 kN) |
| Centrifugal Force - Med | 12139.7 lb (54 kN) |
| Centrifugal Force - Med Low | 9442 lb (42 kN) |
| Centrifugal Force - Low | 6519.5 lb (29 kN) |
Weights
| Operating Weight | 16270 lb (7380 kg) |
Service Refill Capacities
| Fuel Tank Capacity | 35 gal (132.5 L) |
| Water Spray Tank Capacity | 211 gal (798.8 L) |
Vibratory System
| Nominal Amplitude - High | 0.1 in (0.7 mm) |
| Nominal Amplitude - Low | 0.1 in (0.3 mm) |
| Centrifugal Force Per Drum - Maximum | 17550 lb (7960.6 kg) |
| Frequency | 70/53 Hz (4,200/3,200 vpm) |
| Centrifugal Force Per Drum - Minimum | 6525 lb (2959.7 kg) |
