Zoomlion YZ20E
Contents:
| Overall Length | 20.35 in (6200 mm) |
| Overall Width | 7.88 ft in (2400 mm) |
| Height To Top Of Cab | 10.5 ft in (3200 mm) |
| Drum Diameter - Front | 5.25 ft in (1600 mm) |
| Engine Model | BF6L913C |
| Gross Power | 189.1 hp (141 kw) |
| Power Measured @ | 2500 rpm |
| Operating Weight | 44092.5 lb (20000 kg) |
| Max Speed | 6.3 mph (10 km/h) |
| Tires *If Applicable | 20.5-25 |
| Operating Voltage | 24 V |
| Drum Width | 84.7 in (2150 mm) |
| Drum Diameter | 63 in (1600 mm) |
| Static Linear Load | 327.6 lb/in (58.5 kg/cm) |
| Vibration Frequency 1 | 28 Hz |
| Nominal Amplitude - High | 0.1 in (0.9 mm) |
| Vibration Frequency 2 | 32 Hz |
| Nominal Amplitude - Low | 0.1 in (2 mm) |
| Centrifugal Force - High | 62946.5 lb (280 kN) |
| Centrifugal Force - Low | 89923.6 lb (400 kN) |
