Zoomlion YZD20A
Contents:
| Overall Length | 19.43 in (5920 mm) |
| Overall Width | 7.88 ft in (2400 mm) |
| Height To Top Of Cab | 10.5 ft in (3200 mm) |
| Drum Diameter - Front | 5.12 ft in (1560 mm) |
| Engine Model | 6BTA5.9 |
| Gross Power | 177.1 hp (132 kw) |
| Power Measured @ | 2200 rpm |
| Operating Weight | 44092.5 lb (20000 kg) |
| Max Speed | 4.5 mph (7.2 km/h) |
| Tires *If Applicable | 20.5-25 |
| Operating Voltage | 24 V |
| Drum Width | 84.7 in (2150 mm) |
| Drum Diameter | 61.5 in (1560 mm) |
| Static Linear Load | 247.1 lb/in (44.2 kg/cm) |
| Vibration Frequency 1 | 29 Hz |
| Nominal Amplitude - High | 0.1 in (1 mm) |
| Vibration Frequency 2 | 33 Hz |
| Nominal Amplitude - Low | 0.1 in (1.9 mm) |
| Centrifugal Force - High | 53954.2 lb (240 kN) |
| Centrifugal Force - Low | 80931.3 lb (360 kN) |
