Case 621C XT
Browse All Case or Wheel Loader Models
Contents:
Bucket
| Breakout Force | 27808.87 lb (123.7 kN) |
| Bucket Capacity - Heaped | 2.36 yd3 (1.8 m3) |
| Bucket Capacity - Struck | 1.97 yd3 (1.5 m3) |
| Bucket Width | 8.34 ft in (2540 mm) |
Dimensions
| Ground Clearance | 1.4 ft in (425 mm) |
| Width Over Tires | 7.98 ft in (2430 mm) |
| Height To Top Of Cab | 10.7 ft in (3260 mm) |
| Wheelbase | 9.52 ft in (2900 mm) |
| Hinge Pin - Max Height | 12.7 ft in (3870 mm) |
| Transport Height- Maximum | 10695.54 ft in (3260 m) |
| Transport Length, Maximum | 23654.86 ft in (7210 m) |
| Transport Width | 8333.34 ft in (2540 m) |
Engine
| Number Of Cylinders | 6 |
| Engine Model | 6T-590 |
| Compression Ratio | 17.5:1 |
| Net Power | 130.1 hp (97.1 kw) |
| Torque | 424.8 lb ft (575.9 Nm) |
| Gross Power | 139.5 hp (104 kw) |
| Power Measured @ | 2000 rpm |
| Displacement | 359.1 cu in (5.9 L) |
| Torque Measured @ | 1400 rpm |
| Aspiration | Turbocharged |
| Torque Rise | 31 % |
| Bore | 4.1 in (102 mm) |
| Stroke | 4.8 in (120 mm) |
Operational
| Operating Weight | 28810.1 lb (13068 kg) |
| Fuel Capacity | 51 gal (193 L) |
| Hydraulic System Fluid Capacity | 40.5 gal (153 L) |
| Engine Oil Fluid Capacity | 4 gal (15.1 L) |
| Cooling System Fluid Capacity | 6.9 gal (26.1 L) |
| Transmission Fluid Capacity | 2 gal (7.4 L) |
| Front Axle/Diff Fluid Capacity | 2.6 gal (9.5 L) |
| Rear Axle/Diff Fluid Capacity | 2.6 gal (9.5 L) |
| Turning Radius | 17.1 ft in (5190 mm) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 65 amps |
| Tire Size | 20.5 R25 |
Transmission
| Transmission Type | Mechanical w/ electronic control |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 3 |
Hydraulic System
| Pump Flow Capacity | 61.6 gal/min (233.1 L/min) |
| Raise Time | 5.4 sec |
| Dump Time | 1.7 sec |
| Lower Time | 4.4 sec |
