Caterpillar 992G
Browse All Caterpillar or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 15.17 ft in (4626 mm) |
| Bucket Capacity - Heaped | 15 yd3 (11.5 m3) |
| Bucket Capacity - Struck | 12.36 yd3 (9.45 m3) |
| Bucket Width | 15.83 ft in (4824 mm) |
| Breakout Force | 138360 lb (615 kN) |
Dimensions
| Ground Clearance | 2.25 ft in (691 mm) |
| Length With Bucket On Ground | 51.17 ft in (15585 mm) |
| Width Over Tires | 14.82 ft in (4516 mm) |
| Height To Top Of Cab | 18.33 ft in (5590 mm) |
| Wheelbase | 19.33 ft in (5890 mm) |
| Hinge Pin - Max Height | 22.75 ft in (6939 mm) |
| Reach At Max Lift And Dump | 7.58 ft in (2315 mm) |
Dimensions*
| Ground Clearance | 2.27 ft in (0.7 m) |
| Height - Top Of Hood | 13.07 ft in (3.99 m) |
| Height - Top Of Rops/Fops | 18.34 ft in (5.6 m) |
| Hinge Pin Height At Full Lift - Std | 22.77 ft in (6.95 m) |
| Length - Rear Axle To Bumper | 13.76 ft in (4.2 m) |
| Clearance At Maximum Lift/Dump - Std | 18.4 ft in (5.61 m) |
| Overall Height - Bucket Raised - Std | 30.89 ft in (9.42 m) |
| Overall Height - With Bucket Raised | 30.89 ft in (9.42 m) |
| Overall Length - Hl | 53.23 ft in (16.23 m) |
| Overall Length - Std | 51.3 ft in (15.64 m) |
| Reach At Full Lift And 45 Degrees Dump - Hl | 7.56 ft in (2.31 m) |
| Reach At Full Lift And 45 Degrees Dump - Std | 7.6 ft in (2.32 m) |
| Reach At Maximum Lift/Dump - Std | 7.81 ft in (2.39 m) |
| Straight Static Tipping Load - Hl | 129395.76 lb (58692.94 kg) |
| Straight Static Tipping Load - Std | 132920.96 lb (60291.94 kg) |
| Turning Circle - Hl | 75.05 ft in (22.88 m) |
| Turning Circle - Std | 73.07 ft in (22.28 m) |
| Wheel Base Length | 19.32 ft in (5.89 m) |
| Width - Over Tires | 14.82 ft in (4.52 m) |
| Dump Clearance At Full Lift And 45 Degrees Dump - Std | 15.18 ft in (4.63 m) |
| Bucket Pivot - Maximum Lift - Std | 22.77 ft in (6.95 m) |
| Full Turn Static Tipping Load At 40 Degrees - Hl | 111818.33 lb (50719.95 kg) |
| Full Turn Static Tipping Load At 43 Degrees | 113299.83 lb (51391.95 kg) |
| Dump Clearance At Full Lift And 45 Degrees Dump - Hl | 17.22 ft in (5.25 m) |
| Height - Top Of Exhaust Stack | 17.18 ft in (5.24 m) |
Engine
| Number Of Cylinders | 8 |
| Engine Make | 2236 |
| Engine Model | 3508B DITA EUI |
| Net Power | 800 hp (596.6 kw) |
| Gross Power | 880 hp (656.3 kw) |
| Power Measured @ | 1750 rpm |
| Rated Speed | 1750 rpm |
| Displacement | 2105.4 cu in (34.6 L) |
| Torque Measured @ | 1300 rpm |
| Aspiration | twin turbocharged |
| Torque Rise | 30 % |
| Bore | 6.7 in (170 mm) |
| Stroke | 7.5 in (190 mm) |
| Engine Model | Cat 3508B EUI |
| Net Power - Caterpillar | 800.6 hp (597 kw) |
Operational
| Operating Weight | 209278 lb (94927 kg) |
| Fuel Capacity | 413 gal (1562 L) |
| Hydraulic System Fluid Capacity | 84.8 gal (326 L) |
| Engine Oil Fluid Capacity | 26.5 gal (102 L) |
| Cooling System Fluid Capacity | 53.9 gal (204 L) |
| Transmission Fluid Capacity | 44.6 gal (169 L) |
| Front Axle/Diff Fluid Capacity | 91 gal (345 L) |
| Rear Axle/Diff Fluid Capacity | 86 gal (326 L) |
| Static Tipping Weight | 132921 lb (60292 kg) |
| Turning Radius | 36.5 ft in (11136 mm) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 100 amps |
| Rear Axle Oscillation | 20 degrees |
| Tire Size | 45/65 50 ply |
Transmission
| Transmission Type | Powershift |
| Transmission Type | Planetary Powershift |
| Number Of Forward Gears | 3 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 13.5 mph (21.8 km/h) |
| Max Speed - Reverse | 14.9 mph (24 km/h) |
| Forward - 1 | 4.1 mph (6.6 km/h) |
| Forward - 2 | 7.2 mph (11.6 km/h) |
| Forward - 3 | 12.4 mph (20 km/h) |
| Reverse - 1 | 4.6 mph (7.4 km/h) |
| Reverse - 2 | 7.9 mph (12.7 km/h) |
Steering
| Steering | Articulation |
| Steering Angle - Each Direction | 43 degrees |
| Relief Valve Setting | 4496.17 psi |
| Minimum Turning Radius - Over Bucket | 438.5 in (11135.9 mm) |
Transmission
| Reverse - 3 | 13.7 mph (22 km/h) |
Buckets
| Maximum Bucket Capacity | 16 yd3 (12.3 m3) |
| Bucket Capacities | 11.5-12.3 m3 15-16 yd3 |
| Bucket Width | 15.9 ft in (4.9 m) |
Hydraulic System
| Relief Valve Setting | 4500 psi (31000 kPa) |
| Raise Time | 9.2 sec |
| Dump Time | 3.3 sec |
| Lower Time | 3.5 sec |
Axles
| Front | Fixed |
| Rear | Trunnion |
| Oscillation Angle | 10 degrees |
| Maximum Single-Wheel Rise And Fall | 24.8 in (630 mm) |
Operating Specifications
| Cat Truck Match - Standard | 777D |
| Static Tipping Load - Full Turn | 112777 lb (51154.8 kg) |
| Dump Clearance | 19 ft in (5.8 m) |
| Breakout Force | 237825 lb (107875.7 kg) |
| Articulation Angle | 43 degrees |
| Rated Payload | 42920 lb (19468.2 kg) |
| Rated Payload - Standard | 42920 lb (19468.2 kg) |
| Travel Speed | 14.5 mph (23.4 km/h) |
Service Refill Capacities
| Cooling System | 76.7 gal (290.1 L) |
| Fuel Tank | 413 gal (1563.4 L) |
| Crankcase | 27 gal (102.1 L) |
| Hydraulic System - Including Tank | 231.7 gal (877.1 L) |
| Transmission | 44.7 gal (169.1 L) |
| Differential - Final Drives - Front | 91.2 gal (345.1 L) |
| Differential - Final Drives - Rear | 86.2 gal (326 L) |
| Hydraulic System Factory Fill | 170.7 gal (646.1 L) |
| Hydraulic System - Tank Only | 86.2 gal (326 L) |
Hydraulic Cycle Times
| Raise | 9.12 s |
| Dump | 3.3 s |
| Total Hydraulic Cycle Time | 15.9 s |
| Lower Float Down - Empty | 3.47 s |
Cab
| Air Conditioning | Standard |
