Doosan DL500
Browse All Doosan or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 11.02 ft in (3356 mm) |
| Bucket Capacity - Heaped | 6.28 yd3 (4.8 m3) |
| Bucket Width | 11.16 ft in (3400 mm) |
| Breakout Force | 61373 lb (273 kN) |
Dimensions
| Ground Clearance | 1.68 ft in (510 mm) |
| Length With Bucket On Ground | 31.25 ft in (9525 mm) |
| Width Over Tires | 11.16 ft in (3400 mm) |
| Height To Top Of Cab | 12.54 ft in (3820 mm) |
| Wheelbase | 11.82 ft in (3600 mm) |
| Hinge Pin - Max Height | 15.04 ft in (4584 mm) |
| Reach At Max Lift And Dump | 10.24 ft in (3120 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2347 |
| Engine Model | QSM11 |
| Net Power | 335 hp (249.9 kw) |
| Gross Power | 360 hp (268.5 kw) |
| Power Measured @ | 1900 rpm |
| Max Torque | 1236.9 lb ft (1677 Nm) |
| Displacement | 659 cu in (10.8 L) |
| Torque Measured @ | 1400 rpm |
| Aspiration | turbocharged air to air intercooler |
Operational
| Fuel Capacity | 125.8 gal (476 L) |
| Hydraulic System Fluid Capacity | 62.4 gal (236 L) |
| Engine Oil Fluid Capacity | 9 gal (34 L) |
| Cooling System Fluid Capacity | 15.9 gal (60 L) |
| Transmission Fluid Capacity | 14.3 gal (54 L) |
| Front Axle/Diff Fluid Capacity | 13.3 gal (50 L) |
| Rear Axle/Diff Fluid Capacity | 13.3 gal (50 L) |
| Static Tipping Weight | 50706 lb (22999.9 kg) |
| Turning Radius | 24.2 ft in (7370 mm) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 amps |
| Rear Axle Oscillation | 20 degrees |
| Tire Size | 29.5R25 |
Transmission
| Transmission Type | full power shift |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 21.8 mph (35 km/h) |
| Max Speed - Reverse | 15.2 mph (24.4 km/h) |
Hydraulic System
| Relief Valve Setting | 3626 psi (25000 kPa) |
| Pump Flow Capacity | 122.6 gal/min (464 L/min) |
| Raise Time | 6 sec |
| Dump Time | 1.8 sec |
| Lower Time | 4.3 sec |
| Pump Type | axial piston |
