Hitachi LX80-7
Browse All Hitachi or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 8.99 ft in (2740 mm) |
| Bucket Capacity - Heaped | 2.1 yd3 (1.6 m3) |
| Bucket Capacity - Struck | 1.71 yd3 (1.3 m3) |
| Bucket Width | 8.14 ft in (2480 mm) |
| Breakout Force | 17759.91 lb (79 kN) |
Dimensions
| Ground Clearance | 1.2 ft in (365 mm) |
| Length With Bucket On Ground | 20.87 ft in (6360 mm) |
| Width Over Tires | 7.62 ft in (2320 mm) |
| Height To Top Of Cab | 10.31 ft in (3140 mm) |
| Wheelbase | 8.54 ft in (2600 mm) |
| Hinge Pin - Max Height | 11.83 ft in (3605 mm) |
| Reach At Max Lift And Dump | 3.38 ft in (1030 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2353 |
| Engine Model | DD-4BG1T |
| Net Power | 108 hp (80.9 kw) |
| Power Measured @ | 2200 rpm |
| Displacement | 264.2 cu in (4.4 L) |
| Aspiration | Turbocharger |
Operational
| Operating Weight | 17901.6 lb (8120 kg) |
| Fuel Capacity | 41 gal (155 L) |
| Hydraulic System Fluid Capacity | 13.3 gal (50 L) |
| Engine Oil Fluid Capacity | 3.5 gal (13 L) |
| Cooling System Fluid Capacity | 6.1 gal (23 L) |
| Front Axle/Diff Fluid Capacity | 3.7 gal (14 L) |
| Rear Axle/Diff Fluid Capacity | 3.7 gal (14 L) |
| Static Tipping Weight | 13911.2 lb (6310 kg) |
| Turning Radius | 15.4 ft in (4690 mm) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 50 amps |
| Rear Axle Oscillation | 24 degrees |
| Tire Size | 17.5-25-12PR (L2) |
Transmission
| Transmission Type | Two-speed shifts ; high/low speed selection through hydraulic clutch |
| Max Speed - Forward | 21.5 mph (34.5 km/h) |
| Max Speed - Reverse | 21.5 mph (34.5 km/h) |
Hydraulic System
| Relief Valve Setting | 2132.1 psi (14700 kPa) |
| Pump Flow Capacity | 37.3 gal/min (141 L/min) |
| Raise Time | 5.6 sec |
| Dump Time | 1.2 sec |
| Lower Time | 3 sec |
| Pump Type | gear type |
