JCB 411HT
Browse All JCB or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 9.13 ft in (2780 mm) |
| Bucket Capacity - Heaped | 1.57 yd3 (1.2 m3) |
| Bucket Capacity - Struck | 1.33 yd3 (1.01 m3) |
| Bucket Width | 7.39 ft in (2250 mm) |
| Breakout Force | 16456.02 lb (73.2 kN) |
Dimensions
| Ground Clearance | 1.13 ft in (344 mm) |
| Length With Bucket On Ground | 20.44 ft in (6229 mm) |
| Width Over Tires | 7.24 ft in (2204 mm) |
| Height To Top Of Cab | 10.03 ft in (3057 mm) |
| Wheelbase | 9.03 ft in (2750 mm) |
| Hinge Pin - Max Height | 11.71 ft in (3569 mm) |
| Reach At Max Lift And Dump | 3.04 ft in (926 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2257 |
| Engine Model | JCB EcoMAX T4F |
| Engine Type | 4 stroke direct injection |
| Net Power | 85.3 hp (63.7 kw) |
| Gross Power | 109 hp (81.3 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 516 Nm |
| Displacement | 268.6 cu in (4.4 L) |
| Torque Measured @ | 1450 rpm |
| Aspiration | Turbo charged |
| Bore | 4.1 in (103 mm) |
| Stroke | 5.2 in (132 mm) |
Operational
| Def Tank Capacity | 5.3 gal (20 L) |
| Auxiliary Fuel Tank | 29.4 gal (111 L) |
| Operating Weight | 19365.5 lb (8784 kg) |
| Fuel Capacity | 30.7 gal (116 L) |
| Hydraulic System Fluid Capacity | 41 gal (155 L) |
| Engine Oil Fluid Capacity | 3.1 gal (11.5 L) |
| Cooling System Fluid Capacity | 6.1 gal (23 L) |
| Transmission Fluid Capacity | 7.2 gal (27 L) |
| Front Axle/Diff Fluid Capacity | 6.7 gal (25 L) |
| Rear Axle/Diff Fluid Capacity | 6.7 gal (25 L) |
| Static Tipping Weight | 11834.5 lb (5368 kg) |
| Turning Radius | 17.8 ft in (5414 mm) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 100 amps |
| Rear Axle Oscillation | 11 degrees |
| Tire Size | Michelin 15.5R25 XHA (L3) |
| Articulation Angle | 40 degrees |
Transmission
| Transmission Type | Smooth shift Powershift ZF 4WG115 |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 31.1 mph (50 km/h) |
| Max Speed - Reverse | 23.7 mph (38.1 km/h) |
Hydraulic System
| Max Operating Pressure | 220 bar |
| Relief Valve Setting | 3190 psi (21994.3 kPa) |
| Pump Flow Capacity | 13.4 gal/min (50.6 L/min) |
| Raise Time | 5 sec |
| Dump Time | 1.1 sec |
| Lower Time | 3.7 sec |
| Total Cycle | 9.8 sec |
| Pump Type | Double gear pump |
