John Deere 544EH
Browse All John Deere or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 9.36 ft in (2852 mm) |
| Bucket Capacity - Heaped | 2.5 yd3 (1.92 m3) |
| Bucket Capacity - Struck | 2.12 yd3 (1.63 m3) |
| Bucket Width | 8.37 ft in (2550 mm) |
| Breakout Force | 20558 lb (91.45 kN) |
Dimensions
| Ground Clearance | 1.5 ft in (456 mm) |
| Length With Bucket On Ground | 22.68 ft in (6910 mm) |
| Width Over Tires | 7.94 ft in (2420 mm) |
| Height To Top Of Cab | 10.54 ft in (3210 mm) |
| Wheelbase | 9.52 ft in (2900 mm) |
| Hinge Pin - Max Height | 12.44 ft in (3790 mm) |
| Reach At Max Lift And Dump | 3.04 ft in (924 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2240 |
| Engine Model | 6359T |
| Net Power | 125 hp (93.3 kw) |
| Gross Power | 130 hp (97 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 372 lb ft (504 Nm) |
| Displacement | 359 cu in (5.9 L) |
| Torque Measured @ | 1400 rpm |
| Aspiration | Turbocharged |
Operational
| Operating Weight | 23384 lb (10606.9 kg) |
| Fuel Capacity | 55 gal (208 L) |
| Hydraulic System Fluid Capacity | 20.1 gal (76 L) |
| Engine Oil Fluid Capacity | 5.1 gal (19 L) |
| Cooling System Fluid Capacity | 6.4 gal (24 L) |
| Transmission Fluid Capacity | 2.6 gal (9.5 L) |
| Front Axle/Diff Fluid Capacity | 4.3 gal (16 L) |
| Rear Axle/Diff Fluid Capacity | 4.3 gal (16 L) |
| Static Tipping Weight | 17496 lb (7936.1 kg) |
| Turning Radius | 16.2 ft in (4930 mm) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 65 amps |
| Rear Axle Oscillation | 22 degrees |
| Tire Size | 17.5-25 |
Transmission
| Transmission Type | Power Shift |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 25.4 mph (40.9 km/h) |
| Max Speed - Reverse | 17.9 mph (28.8 km/h) |
Hydraulic System
| Relief Valve Setting | 2750 psi (18960.6 kPa) |
| Pump Flow Capacity | 46.3 gal/min (175.3 L/min) |
| Raise Time | 5.8 sec |
| Dump Time | 1.4 sec |
| Lower Time | 3.2 sec |
| Pump Type | Gear |
