John Deere 624GH
Browse All John Deere or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 9.41 ft in (2868 mm) |
| Bucket Capacity - Heaped | 3 yd3 (2.3 m3) |
| Bucket Capacity - Struck | 2.63 yd3 (2 m3) |
| Bucket Width | 8.47 ft in (2580 mm) |
| Breakout Force | 29404 lb (130.81 kN) |
Dimensions
| Ground Clearance | 1.43 ft in (433 mm) |
| Length With Bucket On Ground | 24.32 ft in (7410 mm) |
| Width Over Tires | 8.37 ft in (2549 mm) |
| Height To Top Of Cab | 10.83 ft in (3300 mm) |
| Wheelbase | 9.95 ft in (3030 mm) |
| Hinge Pin - Max Height | 12.77 ft in (3890 mm) |
| Reach At Max Lift And Dump | 3.17 ft in (966 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2240 |
| Engine Model | 6068T |
| Net Power | 150 hp (112 kw) |
| Gross Power | 161 hp (120 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 455 lb ft (617 Nm) |
| Displacement | 414 cu in (6.8 L) |
| Torque Measured @ | 1350 rpm |
| Aspiration | Turbocharger |
Operational
| Operating Weight | 27435 lb (12444.4 kg) |
| Fuel Capacity | 65.8 gal (249 L) |
| Hydraulic System Fluid Capacity | 27 gal (102 L) |
| Engine Oil Fluid Capacity | 5.1 gal (19 L) |
| Cooling System Fluid Capacity | 6.7 gal (25 L) |
| Transmission Fluid Capacity | 3 gal (11 L) |
| Front Axle/Diff Fluid Capacity | 7.4 gal (28 L) |
| Rear Axle/Diff Fluid Capacity | 5.1 gal (19 L) |
| Static Tipping Weight | 21205.1 lb (9618.5 kg) |
| Turning Radius | 16.9 ft in (5129.8 mm) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 95 amps |
| Rear Axle Oscillation | 26 degrees |
| Tire Size | 17.5-25 |
Transmission
| Transmission Type | Power Shift with Torque Converter |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 23 mph (37.3 km/h) |
| Max Speed - Reverse | 15.2 mph (24.5 km/h) |
Hydraulic System
| Relief Valve Setting | 2800 psi (19305.4 kPa) |
| Pump Flow Capacity | 61 gal/min (231 L/min) |
| Raise Time | 5.8 sec |
| Dump Time | 1.7 sec |
| Lower Time | 3.5 sec |
| Pump Type | Gear type , open -center system |
