John Deere 624G
Browse All John Deere or Integrated Tool Carrier Models
Contents:
Dimensions
| Length W/ Bucket On Ground | 24.45 ft in (7450 mm) |
| Width Over Tires | 8.28 ft in (2522 mm) |
| Height To Top Of Cab | 10.83 ft in (3300 mm) |
| Wheelbase | 9.95 ft in (3030 m) |
| Ground Clearance | 1.43 ft in (433 mm) |
| Hinge Pin Max Height | 12.77 ft in (3890 mm) |
| Dump Clearance At Max Lift | 9.4 ft in (2865 mm) |
| Max Lift Height | 11.89 ft in (3623 mm) |
| Fork Tine Length | 4.51 ft in (1372 mm) |
| Hook Height At Max Lift - Standard | 18.38 ft in (5600 mm) |
| Hook Height At Max Lift - Extended | 22.66 ft in (6905 mm) |
| Hook Reach At Max Lift - Standard | 6.5 ft in (1979 mm) |
| Hook Reach At Max Lift - Extended | 11.05 ft in (3368 mm) |
| Length With Out Forks On Ground | 26.17 ft in (7975 mm) |
| Reach At Max Height And Dump | 3.08 ft in (936 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2240 |
| Engine Model | 6068T |
| Gross Power | 145 hp (108 kw) |
| Net Power | 150 hp (112 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 456 lb ft (618 Nm) |
| Torque Measured @ | 1300 rpm |
| Displacement | 414 cu in (6.8 L) |
| Aspiration | Turbocharged |
Operational
| Operating Weight | 27854 lb (12632 kg) |
| Fuel Capacity | 65.7 gal (249 L) |
| Cooling System Fluid Capacity | 6.7 gal (25 L) |
| Engine Oil Capacity | 5.1 gal (19 L) |
| Transmission Fluid Capacity | 3 gal (11 L) |
| Front Diff Fluid Capacity | 7.4 gal (28 L) |
| Rear Diff Fluid Capacity | 5.1 gal (19 L) |
| Hydraulic System Fluid Capacity | 27 gal (102 L) |
| Turning Radius | 16.9 ft in (5140 mm) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 95 amps |
| Rear Axle Oscillation | 26 degrees |
| Static Tipping Load - Bucket | 20107 lb (9120.4 kg) |
| Static Tipping Load - Forks | 15222 lb (6904.6 kg) |
| Static Tipping Load - Material Handler | 10059 lb (4562.7 kg) |
| Tire Size | 17.5-25 |
Transmission
| Transmission Type | Power Shift |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 3 |
| Max Speed Forward | 23 mph (37.3 km/h) |
| Max Speed Reverse | 15.2 mph (24.5 km/h) |
Hydraulic System
| Pump Type | Gear type |
| Relief Valve Setting | 2800 psi (19305.4 kPa) |
| Pump Flow Capacity | 61 gal/min (231 L/min) |
| Raise Time | 5.8 sec |
| Dump Time | 1.7 sec |
| Lower Time | 3.5 sec |
Bucket
| Breakout Force | 27280 lb (121.4 kN) |
| Bucket Capacity - Heaped | 3 yd3 (2.3 m3) |
| Bucket Capacity - Struck | 2.7 yd3 (2.1 m3) |
