Link-Belt ATC822
Browse All Link-Belt or All Terrain Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 27.14 ft in (8.27 m) |
| Max Height @ Max Raise Angle - No Jib | 70.12 ft in (21.37 m) |
| Max Elevating Angle | 78 degrees |
| Number Of Sections | 3 |
| Swing Speed | 2 rpm |
Dimensions
| Transport Length | 32.39 ft in (9870 mm) |
| Transport Width | 8.01 ft in (2440 mm) |
| Transport Height | 10.08 ft in (3070 mm) |
| Ground Clearance | 1.35 ft in (410 mm) |
| Width W/ Outriggers Extended | 19.89 ft in (6060 mm) |
| Carrier Length | 25.46 ft in (7760 mm) |
| Upper Structure Tail Swing Radius | 11.09 ft in (3380 mm) |
Upper Structure Engine
| Make | Link-Belt |
Carrier Engine
| Stroke | 4.8 in (119.9 mm) |
| Bore | 4.1 in (102.2 mm) |
| Make | Link-Belt |
| Model | ISB 230 |
| Gross Power | 230 hp (171.6 kw) |
| Power Measured @ | 2500 rpm |
| Max Torque | 605 lb ft (820.3 Nm) |
| Torque Measured @ | 1500 rpm |
| Displacement | 359 cu in (5.9 L) |
| Number Of Cylinders | 6 |
Operational
| Operating Weight | 39222.5 lb (17791 kg) |
| Carrier Fuel Capacity | 40 gal (151.5 L) |
| Upper Structure Hydraulic System Fluid Capacity | 63 gal (238.5 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 130 amps |
| Tire Size | 16.0 R 20 |
Transmission
| Transmission Type | ZF full powershift |
| Number Of Forward Gears | 6 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 55 mph (88.5 km/h) |
