Ingersoll Rand PF150
Browse All Ingersoll Rand or Asphalt Paver Models
Contents:
Dimensions
| Length W/ Screed | 15.26 ft in (4650 mm) |
| Transport Width | 8.21 ft in (2500 mm) |
| Transport Height | 9.75 ft in (2970 mm) |
| Wheelbase | 7.01 ft in (2134 mm) |
| Width W/ Hopper Open | 10.44 ft in (3180 mm) |
Engine
| Engine Make | 2349 |
| Engine Model | F3L912 |
| Net Power | 47 hp (35.1 kw) |
Operational
| Operating Weight W/O Screed | 12290.8 lb (5575 kg) |
| Operating Weight W/ Screed | 15289.1 lb (6935 kg) |
| Fuel Capacity | 30.2 gal (114 L) |
| Hydraulic System Fluid Capacity | 24.1 gal (91 L) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 62 amps |
Hopper/Paver
| Hopper Capacity | 4 lb (3.1 kg) |
| Paving Width - Std | 8.1 ft in (2440 mm) |
| Paving Width - Max | 13 ft in (3960 mm) |
| Paving Thickness - Max | 6 in (152.4 mm) |
| Paving Speed - Max | 133.9 ft/min (40.8 m/min) |
| Travel Speed - Max | 11.7 mph (18.7 km/h) |
| Auger Diameter | 11 in (279 mm) |
