Ingersoll Rand 3120
Browse All Ingersoll Rand or Asphalt Paver Models
Contents:
Dimensions
| Length W/ Screed | 13.13 ft in (4000 mm) |
| Transport Width | 8.54 ft in (2600 mm) |
| Transport Height | 6.24 ft in (1900 mm) |
| Track Width | 12.01 in (305 mm) |
| Width W/ Hopper Open | 9.19 ft in (2800 mm) |
Engine
| Engine Make | 2334 |
| Net Power | 87 hp (64.9 kw) |
| Aspiration | turbocharged |
Operational
| Operating Weight W/ Screed | 16958 lb (7692 kg) |
| Fuel Capacity | 28.1 gal (106 L) |
Hopper/Paver
| Paving Width - Std | 8 ft in (2438.4 mm) |
| Paving Width - Max | 14.8 ft in (4500 mm) |
| Paving Thickness - Max | 6 in (152.4 mm) |
| Paving Speed - Max | 119.8 ft/min (36.5 m/min) |
| Travel Speed - Max | 3.5 mph (5.5 km/h) |
| Auger Diameter | 10 in (254 mm) |
