Massey Ferguson 1746
Browse All Massey Ferguson or Baler Models
Contents:
Baler Pickup
| Overall Width | 3.9 ft in (1.19 m) |
| Number Of Tines | 72 |
| Tine To Tine Width | 3.69 ft in (1.13 m) |
| Number Of Bars | 4 |
Dimensions
| Overall Length | 13.51 ft in (4115 mm) |
| Overall Width | 8.37 ft in (2550 mm) |
| Overall Height | 9.85 ft in (3000 mm) |
| Tractor Pto Power Required | 55 hp (41.02 kw) |
| Weight | 5100 lb (2313.33 kg) |
Bale Size
| Bale Width | 3.9 ft in (1182 mm) |
| Bale Diameter - Min | 2.5 ft in (762 mm) |
| Bale Diameter - Max | 6.1 ft in (1829 mm) |
| Bale Weight - Min | 1500 lb (680.4 kg) |
Bale Chamber
| Number Of Belts | 6 Laced, WedgeGrip Pattern |
| Belt Width | 7 in (17.8 cm) |
Wrapping System
| Twine Type | AutoTie - Electric Actuated |
| Twine Ball Capacity | 4 |
