Toyota 7FBCU45
Contents:
Dimensions
| Length To Fork Face | 8.63 ft in (2630 mm) |
| Overall Width | 4.43 ft in (1350 mm) |
| Wheelbase | 5.11 ft in (1555 mm) |
| Height To Top Of Overhead Guard | 7.52 ft in (2290 mm) |
| Max Fork Height | 10.01 ft in (3050 mm) |
| Free Lift | 4.34 in (110 mm) |
| Front Wheel Tread Width | 41.15 in (1045 mm) |
| Gradeability | 13 % |
| Rear Wheel Tread Width - Max | 42.52 in (1080 mm) |
| Right Angle Stack | 8.9 ft in (2710 mm) |
| Turning Radius | 7.3 ft in (2225 mm) |
Mast
| Lift Speed | 57 ft/min (17.38 m/min) |
| Lower Speed | 98 ft/min (29.88 m/min) |
| Load Center | 24 in (609.6 mm) |
| Load Capacity | 10000 lb (4535.93 kg) |
Electrical System
| Control Power Steering | Transistor Chopper |
| Control Drive | Transistor Invertor |
| Battery Voltage | 36 V/Ah |
| Battery Capacity | 1360 V/Ah |
| Battery | 48 |
Engine
| Fuel Type | Electric |
Operational
| Operating Weight | 12570 lb (5701.7 kg) |
| Tire Type | cushion |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 10.9 mph (17.6 km/h) |
| Drawbar Pull | 3650 lb (1655.7 kg) |
| Tire Size | Front - 22 x 12 x 16, Rear - 18 x 7 x 12-1/8 |
| Hydraulic System Relief Valve Pressure | 2630 psi (18133.2 kPa) |
