Toyota 7FBCU35
Contents:
Dimensions
| Length To Fork Face | 8.24 ft in (2510 mm) |
| Overall Width | 3.97 ft in (1210 mm) |
| Wheelbase | 5.11 ft in (1555 mm) |
| Height To Top Of Overhead Guard | 7.5 ft in (2285 mm) |
| Max Fork Height | 10.01 ft in (3050 mm) |
| Free Lift | 4.34 in (110 mm) |
| Front Wheel Tread Width | 38.59 in (980 mm) |
| Gradeability | 16 % |
| Rear Wheel Tread Width - Max | 41.34 in (1050 mm) |
| Right Angle Stack | 8.55 ft in (2605 mm) |
| Turning Radius | 7.03 ft in (2140 mm) |
Mast
| Lift Speed | 72.91 ft/min (22.22 m/min) |
| Lower Speed | 98 ft/min (29.88 m/min) |
| Load Center | 24 in (609.6 mm) |
| Load Capacity | 8000 lb (3628.74 kg) |
Electrical System
| Control Load Handling | Transistor Chopper |
| Control Drive | Transistor Invertor |
| Control Power Steering | Transistor Chopper |
| Battery Voltage | 48 V/Ah |
| Battery Capacity | 1105 V/Ah |
Engine
| Fuel Type | Electric |
Operational
| Operating Weight | 23038.4 lb (10450 kg) |
| Tire Type | cushion |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 10.9 mph (17.6 km/h) |
| Drawbar Pull | 3800 lb (1723.7 kg) |
| Tire Size | Front - 22 x 9 x 16, Rear - 18 x 6 x 12-1/8 |
| Hydraulic System Relief Valve Pressure | 2630 psi (18133.2 kPa) |
