Sany SY310
Browse All Sany or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 35.88 ft in (10935 mm) |
| Shipping Height Of Unit | 10.68 ft in (3255 mm) |
| Max Loading Height | 23.33 ft in (7110 mm) |
| Max Reach Along Ground | 36.42 ft in (11100 mm) |
| Max Vertical Wall Digging Depth | 21.26 ft in (6480 mm) |
| Max Digging Depth | 24.22 ft in (7380 mm) |
Dimensions
| Ground Clearance | 1.65 ft in (500 mm) |
| Width To Outside Of Tracks | 10.47 ft in (3190 mm) |
| Length Of Track On Ground | 12.14 ft in (3700 mm) |
| Tail Swing Radius | 10.47 ft in (3190 mm) |
Undercarriage
| Shoe Size | 23.63 in (600 mm) |
| Max Travel Speed | 3.11 mph (5 km/h) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2347 |
| Engine Model | QSB8.3 |
| Gross Power | 260.2 hp (194 kw) |
| Power Measured @ | 2000 rpm |
| Displacement | 506.5 cu in (8.3 L) |
Operational
| Operating Weight | 66800.1 lb (30300 kg) |
| Hydraulic Pump Flow Capacity | 140.1 gal/min (530 L/min) |
Buckets
| Reference Bucket Capacity | 1.9 yd3 (1.4 m3) |
