Tata Hitachi ZAXIS120H
Browse All Tata Hitachi or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Max Cutting Height | 27.47 ft in (8370 mm) |
| Max Loading Height | 19.56 ft in (5960 mm) |
| Max Reach Along Ground | 25.5 ft in (7770 mm) |
| Max Vertical Wall Digging Depth | 15.26 ft in (4650 mm) |
| Max Digging Depth | 16.9 ft in (5150 mm) |
| Boom/Stick Option (Hex) 1 | Boom 15'1" (4600mm)/Stick 6'11" (2100mm) |
Dimensions
| Ground Clearance | 1.45 ft in (440 mm) |
| Height To Top Of Cab | 8.99 ft in (2740 mm) |
| Width To Outside Of Tracks | 8.17 ft in (2490 mm) |
| Length Of Track On Ground | 9.45 ft in (2880 mm) |
| Tail Swing Radius | 6.99 ft in (2130 mm) |
| Removal Counterweight Clearance | 2.92 ft in (890 mm) |
Undercarriage
| Track Gauge | 6.53 ft in (1990 mm) |
| Shoe Size | 19.69 in (500 mm) |
| Ground Pressure | 5.37 psi (37 kPa) |
| Number Of Carrier Rollers Per Side | 1 |
| Number Of Shoes Per Side | 44 |
| Number Of Track Rollers Per Side | 7 |
| Max Travel Speed | 3.42 mph (5.5 km/h) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2353 |
| Engine Model | CC-4BG1TC |
| Net Power | 88.6 hp (66 kw) |
| Power Measured @ | 2150 rpm |
| Max Torque | 250.8 lb ft (340 Nm) |
| Displacement | 264.2 cu in (4.4 L) |
| Aspiration | turbocharged |
| Torque Measured @ | 600 rpm |
Operational
| Operating Weight | 28219.2 lb (12800 kg) |
| Fuel Capacity | 66.1 gal (250 L) |
| Cooling System Fluid Capacity | 5.1 gal (19 L) |
| Hydraulic System Fluid Capacity | 34.4 gal (130 L) |
| Operating Voltage | 24 V |
| Engine Oil Capacity | 4.2 gal (15.8 L) |
| Swing Drive Fluid Capacity | 0.9 gal (3.2 L) |
| Hydraulic System Relief Valve Pressure | 4980 psi (34335.9 kPa) |
| Hydraulic Pump Flow Capacity | 55.5 gal/min (210 L/min) |
Swing Mechanism
| Swing Speed | 13.7 rpm |
Buckets
| Reference Bucket Capacity | 1 yd3 (0.7 m3) |
| Minimum Bucket Capacity | 0.3 yd3 (0.2 m3) |
| Maximum Bucket Capacity | 1 yd3 (0.7 m3) |
