Terex T560
Browse All Terex or Hydraulic Truck Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 35 ft in (10.67 m) |
| Max Height @ Max Raise Angle - No Jib | 110 ft in (33.53 m) |
| Max Elevating Angle | 76 degrees |
| Number Of Sections | 4 |
Dimensions
| Transport Length | 43.08 ft in (13130 mm) |
| Transport Width | 8.42 ft in (2565 mm) |
| Transport Height | 11.09 ft in (3380 mm) |
| Ground Clearance | 1.35 ft in (410 mm) |
| Width W/ Outriggers Extended | 23 ft in (7010 mm) |
| Carrier Length | 38.59 ft in (11760 mm) |
| Upper Structure Tail Swing Radius | 11.91 ft in (3630 mm) |
Carrier Engine
| Make | Terex |
| Model | 60 Series |
| Gross Power | 430 hp (320.7 kw) |
| Displacement | 775.1 cu in (12.7 L) |
Operational
| Carrier Fuel Capacity | 100 gal (378.6 L) |
| Carrier Hydraulic System Fluid Capacity | 117 gal (442.9 L) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 130 amps |
