John Deere 410G
Browse All John Deere or Loader Backhoe Models
Contents:
Backhoe
| Load Height - Std | 12.5 ft in (3810 mm) |
| Reach From Swivel - Std | 19.68 ft in (5990 mm) |
| Dig Depth - Std | 15.83 ft in (4830 mm) |
| Reach At Load Height - Std | 23.33 ft in (7110 mm) |
| Bucket Dig Force - Std | 14801 lb (6713.63 kg) |
| Bucket Dig Force - Ext | 14801 lb (6713.63 kg) |
| Reach From Swivel - Ext | 23.67 ft in (7210 mm) |
| Dig Depth - Ext | 20.5 ft in (6100 mm) |
| Reach At Load Height - Ext | 27.33 ft in (8330 mm) |
| Load Height - Ext | 15.5 ft in (4720 mm) |
Dimensions
| Transport Length | 23.92 ft in (7290 mm) |
| Transport Width | 7.55 ft in (2300 mm) |
| Transport Height | 12.83 ft in (3910 mm) |
| Wheelbase | 6.89 ft in (2100 mm) |
| Ground Clearance | 1.17 ft in (356 mm) |
| Height To Top Of Suspended Cab | 9.25 ft in (2820 mm) |
Loader
| Clearance At Max Dump Height | 12.33 ft in (3758.19 mm) |
| Reach At Max Dump Height | 2.96 ft in (902 mm) |
| Dig Depth | 4.2 in (107 mm) |
| Lift Capacity At Full Height | 7340 lb (3332 kg) |
| Bucket Capacity | 1.25 yd3 (0.96 m3) |
| Bucket Width | 36 in (914 mm) |
| Bucket Breakout Force | 10210 lb (45.4 kN) |
Engine
| Engine Make | 2240 |
| Engine Model | 4045T |
| Net Power | 96 hp (71.6 kw) |
| Power Measured @ | 2100 rpm |
| Torque Measured @ | 1400 rpm |
| Net Torque Rise | 23 % |
| Net Max Torque | 279 lb ft (378.3 Nm) |
| Aspiration | Turbocharged |
Operational
| Operating Weight 2wd | 1628 lb (738 kg) |
| Fuel Capacity | 36 gal (136 L) |
| Operating Weight 4wd | 1262 lb (572 kg) |
| Max Weight | 15000 lb (6804 kg) |
| Hydraulic System Fluid Capacity | 26 gal (98 L) |
| Oil System Fluid Capacity | 3.5 gal (13 L) |
| Cooling System Fluid Capacity | 4.3 gal (16 L) |
| Transmission Fluid Capacity | 4 gal (15 L) |
| Front Axle Fluid Capacity | 2 gal (7.6 L) |
| Rear Axle Fluid Capacity | 4.2 gal (16 L) |
| Turning Radius | 11.7 ft in (3560 mm) |
| Tire Size Front - 2wd / 4wd | 11L-16 F3 |
| Rear Tires Size 2wd/4wd | 19.5L-24 R4 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 90 amps |
Transmission
| Transmission Type | 4-speed, helical cut gear, full power shifted transmission with hydraulic reverser |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 20.5 mph (33 km/h) |
| Max Speed Reverse | 16.1 mph (25.9 km/h) |
Hydraulic
| Pump Type | Axial-piston, PCLS system |
| Pump Flow Capacity | 43 gal/min (163 L/min) |
| Relief Valve Pressure | 3625 psi (25000 kPa) |
