New Holland B90B
Browse All New Holland or Loader Backhoe Models
Contents:
Backhoe
| Load Height - Std | 19.08 ft in (5815 mm) |
| Reach From Swivel - Std | 4.34 ft in (1320 mm) |
| Dig Depth - Std | 15.46 ft in (4710 mm) |
| Reach At Load Height - Std | 7.65 ft in (2330 mm) |
| Dig Depth - Ext | 18.87 ft in (5750 mm) |
| Bucket Dig Force - Std | 13827.4 lb (6272 kg) |
| Reach At Load Height - Ext | 10.47 ft in (3190 mm) |
| Load Height - Ext | 21.25 ft in (6475 mm) |
Dimensions
| Transport Length | 19.12 ft in (5825 mm) |
| Transport Width | 7.63 ft in (2325 mm) |
| Transport Height | 12.72 ft in (3875 mm) |
| Wheelbase | 7.14 ft in (2175 mm) |
| Height To Top Of Suspended Cab | 9.65 ft in (2940 mm) |
Loader
| Clearance At Max Dump Height | 9.13 ft in (2780 mm) |
| Reach At Max Dump Height | 2.58 ft in (785 mm) |
| Dig Depth | 2.96 in (75 mm) |
| Lift Capacity At Full Height | 7826.41 lb (3550 kg) |
| Bucket Capacity | 1.31 yd3 (1 m3) |
| Bucket Breakout Force | 15511.82 lb (69 kN) |
Engine
| Gross Power | 97 hp (72.4 kw) |
| Power Measured @ | 2200 rpm |
| Torque Measured @ | 1250 rpm |
| Net Max Torque | 295.1 lb ft (400 Nm) |
| Aspiration | Turbocharged |
| Displacement | 274.7 cu in (4.5 L) |
Operational
| Fuel Capacity | 38.4 gal (145 L) |
| Max Weight | 17570.9 lb (7970 kg) |
| Cooling System Fluid Capacity | 6.4 gal (24 L) |
| Turning Radius | 14.2 ft in (4300 mm) |
| Tire Size Front - 2wd / 4wd | 18 inches |
| Rear Tires Size 2wd/4wd | 26 inches |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 900 amps |
Transmission
| Transmission Type | Powershift |
Hydraulic
| Pump Type | Twin Gear Pump |
| Pump Flow Capacity | 39.9 gal/min (151 L/min) |
| Relief Valve Pressure | 2973.3 psi (20500 kPa) |
