Yanmar ViO17-A
Browse All Yanmar or Midi Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Max Digging Depth | 7.7 ft in (2346.96 mm) |
| Boom Swing - Right | 65 degrees |
| Boom Swing - Left | 42 degrees |
Dimensions
| Width To Outside Of Tracks | 3.12 ft in (950 mm) |
| Length Of Track On Ground | 11.32 ft in (3450 mm) |
| Ground Clearance | 0.58 ft in (175 mm) |
| Height To Top Of Cab | 7.55 ft in (2300 mm) |
| Tail Swing Radius | 2.1 ft in (640 mm) |
Undercarriage
| Ground Pressure | 4.1 psi (28.27 kPa) |
| Max Travel Speed | 2.7 mph (4.35 km/h) |
Engine
| Engine Make | YANMAR |
| Engine Model | 3TNV74F-SPBV |
| Gross Power | 14.5 hp (10.9 kw) |
| Power Measured @ | 2400 rpm |
Operational
| Operating Weight | 3836.1 lb (1740 kg) |
| Fuel Capacity | 5.3 gal (20 L) |
| Hydraulic Pump Flow Capacity | 15.2 gal/min (57.6 L/min) |
Swing Mechanism
| Swing Speed | 9.5 rpm |
Buckets
| Bucket Digging Force - Sae | 3418 lb (15.3 kN) |
