Komatsu PC02-1
Browse All Komatsu or Mini Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 7.55 ft in (2300 mm) |
| Max Cutting Height | 7.22 ft in (2200 mm) |
| Max Loading Height | 5.09 ft in (1550 mm) |
| Max Reach Along Ground | 7.62 ft in (2320 mm) |
| Max Vertical Wall Digging Depth | 3.09 ft in (940 mm) |
| Max Digging Depth | 4.27 ft in (1300 mm) |
| Boom/Stick Option (Hex) 1 | Boom 3'8" (1130mm)/Stick 1'11" (575mm) |
Dimensions
| Width To Outside Of Tracks | 2.27 ft in (690 mm) |
| Length Of Track On Ground | 2.6 ft in (792 mm) |
| Ground Clearance | 0.5 ft in (150 mm) |
| Tail Swing Radius | 2.3 ft in (700 mm) |
| Removal Counterweight Clearance | 1.07 ft in (325 mm) |
Undercarriage
| Shoe Size | 5.91 in (150 mm) |
| Track Gauge | 1.78 ft in (540 mm) |
| Max Travel Speed | 1 mph (1.6 km/h) |
| Ground Pressure | 2.8 psi (19.31 kPa) |
Engine
| Engine Make | 2238 |
| Engine Model | 1D75 |
| Gross Power | 4.5 hp (3.3 kw) |
| Power Measured @ | 2500 rpm |
| Displacement | 16.7 cu in (0.3 L) |
Operational
| Operating Weight | 1168.5 lb (530 kg) |
| Fuel Capacity | 1 gal (3.5 L) |
| Hydraulic System Fluid Capacity | 2 gal (7.5 L) |
| Hydraulic System Relief Valve Pressure | 2130 psi (14685.9 kPa) |
| Hydraulic Pump Flow Capacity | 3.3 gal/min (12.4 L/min) |
Swing Mechanism
| Swing Speed | 7.5 rpm |
Buckets
| Reference Bucket Capacity | 0.1 yd3 (0.1 m3) |
