New Holland E33C
Browse All New Holland or Mini Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Max Vertical Wall Digging Depth | 6.8 ft in (2072.64 mm) |
| Max Digging Depth | 9.11 ft in (2776.73 mm) |
| Max Digging Reach | 17 ft in (5181.61 mm) |
| Max Digging Reach On Ground | 16.7 ft in (5090.16 mm) |
| Bucket Digging Force | 6900 lb (30.7 kN) |
| Overall Reach Height | 15.3 ft in (4663.44 mm) |
| Arm Digging Force | 4390 lb (19.53 kN) |
| Max.Dumping Height | 10.9 ft in (3322.32 mm) |
Dimensions
| Tail Swing Radius | 2.55 ft in (775 mm) |
| Arm (Standard Length) | 4.27 ft in (1.3 m) |
| Upper Structure Ground Clearance | 1.78 ft in (540 mm) |
| Center To Center – Idler To Sprocket | 5.58 ft in (1700 mm) |
| Minimum Ground Clearance | 11.42 in (290 mm) |
| Operating Weight(Canpoy) | 7109.91 lb (3225 kg) |
| Overall Height | 8.21 ft in (2500 mm) |
| Overall Track Length | 6.99 ft in (2130 mm) |
| Overall Track Width | 5.09 ft in (1550 mm) |
| Overall Transport Length | 182.68 in (4640 mm) |
| Track Shoe Width | 0.99 ft in (300 mm) |
Engine
| Emissions Certification | Tier 4 Final |
| Fuel | Diesel |
| Cylinders | 3 |
| Gross Horsepower – Sae J1995 | 24.4 hp (18.2 kw) |
| Fuel Injection | Mechanical with electronic governor |
| Cooling Method | Water-cooled |
| Engine Model | Yanmar 3TNV88F-ESHYB |
| Displacement | 100.2 cu in (1.7 L) |
Drive Train
| Travel Speeds - 1st | 1.5 mph (2.5 km/h) |
| Travel Speeds - 2nd | 2.6 mph (4.2 km/h) |
| Maximum Traction Force | 6834.2 lb (30.4 kN) |
| Gradeability | 30 degrees |
Capacities
| Engine Oil W/ Filter Change | 1.8 gal (6.7 L) |
| Hydraulic Tank - Refill Capacity | 7.2 gal (27 L) |
| Hydraulic Tank - Total System | 14.6 gal (55 L) |
| Fuel Tank | 8 gal (30 L) |
| Radiator | 1.5 gal (5.5 L) |
Performance
| Maximum Dig Radius | 204 in (5180 mm) |
| Dig Radius At Groundline | 199.3 in (5060 mm) |
| Maximum Dig Depth | 119.5 in (3035 mm) |
| Vertical Straight Wall Dig Depth | 80 in (2030 mm) |
Blade
| Backfill Blade Height | 13 in (330 mm) |
| Backfill Blade Width | 61.1 in (1550 mm) |
| Backfill Blade Dig Depth | 17.2 in (435 mm) |
| Backfill Blade Rise Above Ground | 15.8 in (400 mm) |
