Thomas 15V
Browse All Thomas or Mini Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 12.28 ft in (3740 mm) |
| Max Cutting Height | 11.09 ft in (3380 mm) |
| Max Loading Height | 7.6 ft in (2315 mm) |
| Max Vertical Wall Digging Depth | 5.81 ft in (1770 mm) |
| Max Digging Depth | 7.71 ft in (2350 mm) |
Dimensions
| Width To Outside Of Tracks | 4.27 ft in (1300 mm) |
| Length Of Track On Ground | 3.71 ft in (1130 mm) |
| Height To Top Of Cab | 7.42 ft in (2260 mm) |
| Tail Swing Radius | 3.75 ft in (1140 mm) |
Undercarriage
| Shoe Size | 9.06 in (230 mm) |
| Track Gauge | 2.6 ft in (790 mm) |
| Max Travel Speed | 2.43 mph (3.9 km/h) |
Engine
| Engine Make | 2251 |
| Engine Model | L3E |
| Gross Power | 16.8 hp (12.5 kw) |
| Power Measured @ | 2400 rpm |
| Displacement | 58.1 cu in (1 L) |
Operational
| Operating Weight | 3307 lb (1500 kg) |
| Fuel Capacity | 6.3 gal (23.6 L) |
| Hydraulic System Relief Valve Pressure | 8106 psi (55888.9 kPa) |
| Hydraulic Pump Flow Capacity | 12.3 gal/min (46.6 L/min) |
Swing Mechanism
| Swing Speed | 11.5 rpm |
